Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 27.5" / 29" -
Travel Front 130mm -
Fork RockShox Pike RC
-
Groupset X01 Eagle, Truvativ Descendant Carbon -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
MD
168cm - 180cm
MD
168cm - 180cm
MD
168cm - 180cm
LG
178cm - 189cm
LG
178cm - 189cm
LG
178cm - 189cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ONE-TWENTY CFA
Suspension Fork
Rock Shox Pike RC Air fork with tapered steerer, 130mm travel and 15mm bolt through
Rear Shock
Rock Shox Monarch RT3
Drivetrain
Rear Derailleur
SRAM X01 Eagle
Shift Levers
SRAM X01 Eagle trigger 12 speed with SRAM MMX clamp
Cassette
SRAM X01 Eagle, 12 speed, 10-50 teeth
Crank
SRAM Descendant carbon Eagle 32 teeth
Chain
SRAM X01 Eagle
Wheels
Rims
DT Swiss Spline EX 1501 ONE 30 wheelset, Boost standard, 15mm front, 12mm rear bolt through axles
Tires
Continental Mountain King II 2.4" ProTection
Brakes
Brakes
SRAM Code RSC hydraulic disc, 180mm rotors
Brake Levers
SRAM Code RSC
Cockpit
Handlebar
MERIDA Expert TR double butted 6061 aluminium, 35mm rise, 760mm wide
Headset
MERIDA M2339
Seat
Saddle
Prologo Nago X20
Seatpost
Rock Shox Reverb Stealth 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | MD | MD | MD | LG | LG | LG | LG | XL |
|---|---|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.38 mm | 1.38 mm | 1.43 mm | 1.43 mm | 1.39 mm | 1.39 mm | 1.34 mm | 1.34 mm | 1.35 mm |
| Bottom Bracket Height | 330 mm | 330 mm | 349 mm | 315 mm | 334 mm | 315 mm | 334 mm | 330 mm | 349 mm | 334 mm |
| Front Center | 683 mm | 703 mm | 703 mm | 702 mm | 702 mm | 725 mm | 725 mm | 728 mm | 728 mm | 749 mm |
| Rake | 40 mm | 40 mm | 40 mm | 46 mm | 46 mm | 46 mm | 46 mm | 39 mm | 39 mm | 46 mm |
| Trail | 100 mm | 100 mm | 108 mm | 87 mm | 94 mm | 87 mm | 94 mm | 102 mm | 109 mm | 94 mm |
| Stack | 587 mm | 591 mm | 591 mm | 613 mm | 613 mm | 622 mm | 622 mm | 601 mm | 601 mm | 631 mm |
| Reach | 410 mm | 428 mm | 428 mm | 429 mm | 429 mm | 448 mm | 448 mm | 450 mm | 450 mm | 469 mm |
| Top Tube Length | 573 mm | 593 mm | 593 mm | 593 mm | 593 mm | 616 mm | 616 mm | 618 mm | 618 mm | 640 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 75 ° | 75 ° | 75 ° | 75 ° | 74.5 ° | 74.5 ° | 75 ° |
| Seat Tube Length | 415 mm | 450 mm | 450 mm | 450 mm | 450 mm | 500 mm | 500 mm | 500 mm | 500 mm | 550 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 69 ° | 69 ° | 69 ° | 69 ° | 68 ° | 68 ° | 69 ° |
| Head Tube Length | 105 mm | 110 mm | 110 mm | 95 mm | 95 mm | 105 mm | 105 mm | 120 mm | 120 mm | 115 mm |
| Chainstay Length | 438 mm | 438 mm | 438 mm | 443 mm | 443 mm | 443 mm | 443 mm | 438 mm | 438 mm | 443 mm |
| Wheelbase | 1120 mm | 1140 mm | 1140 mm | 1142 mm | 1142 mm | 1165 mm | 1165 mm | 1165 mm | 1165 mm | 1189 mm |
| Bottom Bracket Drop | 25 mm | 25 mm | 25 mm | 40 mm | 40 mm | 40 mm | 40 mm | 25 mm | 25 mm | 40 mm |
| Standover Height | 708 mm | 730 mm | 730 mm | 738 mm | 738 mm | 766 mm | 766 mm | 754 mm | 754 mm | 771 mm |
| Wheels | 27" | 27" | 29" | 27" | 29" | 27" | 29" | 27" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 168 cm | 168 cm | 168 cm | 178 cm | 178 cm | 178 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 180 cm | 180 cm | 180 cm | 189 cm | 189 cm | 189 cm | 189 cm | 199 cm |
About this model
ONE-TWENTY 8000 is a Merida One Twenty model. There are 86 bikes that carry this model name. You can get a glimpse at all models from 2018, by clicking on this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Trail bikes
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Average weight for Trail bikes
Trail bikes have an average weight of 12.98 kg (28.62 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
slightly lighter than average, ONE-TWENTY 8000 has a weight of 12.9 kg (28.44 lbs). To sum up, it’s 0.62% lighter than the average weight of Trail bikes.
ONE-TWENTY 8000 components
Fork
The fork installed on this bike is the RockShox Pike RC model. The travel on this model is 130mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
As for the wheels, Merida ONE-TWENTY 8000 2018, has a 27.5″ aluminum model. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Merida ONE-TWENTY 8000 has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
Merida ONE-TWENTY 8000 bike has 10 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
The Merida model is also equipped with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
