Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 700c -
Groupset 105, FSA -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
REACTO LITE
Suspension Fork
Race Full carbon tapered fork with conventional brake mounts
Drivetrain
Rear Derailleur
Shimano 105
Front Derailleur
Shimano 105
Shift Levers
Shimano 105, 22 speed
Cassette
Shimano CS-5800, 11 speed, 11-28 teeth
Crank
FSA Gossamer 52-36 teeth Mega
Chain
KMC X11-1
Wheels
Front Hub
Sealed bearing with quick release
Rear Hub
Sealed bearing with quick release
Rims
MERIDA Expert CW, 30mm profile
Spokes
Black stainless
Tires
Maxxis Dolomites 25c folding
Brakes
Brakes
Shimano 105 with MERIDA brake calipers (rear direct mount)
Brake Levers
Shimano 105
Cockpit
Handlebar
MERIDA Expert Aero double butted 6061 aluminium compact drop, oversize clamp
Headset
MERIDA M2331
Seat
Saddle
MERIDA Race
Seatpost
Reacto carbon
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | SM/MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.35 mm | 1.36 mm | 1.35 mm | 1.39 mm | 1.42 mm | 1.45 mm |
| Bottom Bracket Height | 275 mm | 275 mm | 275 mm | 275 mm | 275 mm | 275 mm |
| Front Center | 577 mm | 581 mm | 587 mm | 597 mm | 607 mm | 622 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 46 mm |
| Trail | 68 mm | 62 mm | 56 mm | 56 mm | 56 mm | 55 mm |
| Stack | 508 mm | 521 mm | 534 mm | 553 mm | 572 mm | 596 mm |
| Reach | 375 mm | 383 mm | 395 mm | 399 mm | 403 mm | 410 mm |
| Top Tube Length | 520 mm | 532 mm | 547 mm | 562 mm | 577 mm | 592 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 470 mm | 500 mm | 520 mm | 540 mm | 560 mm | 590 mm |
| Head Tube Angle | 71 ° | 72 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 120 mm | 130 mm | 140 mm | 160 mm | 180 mm | 205 mm |
| Chainstay Length | 407 mm | 407 mm | 407 mm | 407 mm | 407 mm | 407 mm |
| Wheelbase | 976 mm | 980 mm | 986 mm | 996 mm | 1006 mm | 1021 mm |
| Bottom Bracket Drop | 61 mm | 61 mm | 61 mm | 61 mm | 61 mm | 61 mm |
| Standover Height | 742 mm | 768 mm | 786 mm | 804 mm | 822 mm | 850 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
REACTO 400 belongs to the Merida Reacto model. There are 111 bikes that carry this model name. You can easily view all of the Merida Reacto bikes models from 2018, here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Aero bikes average price
According to our calculations, the average cost of an Aero bike that is reliable is 4211$. However, you could also get a good Aero bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Aero bikes average weight
Aero bikes weigh an average of 7.34 kg (16.18 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
REACTO 400 weighs 9.35 kg (20.61 lbs) and is much heavier than the average. To sum up, it’s 27.38% heavier than the average weight of Aero bikes.
Overview of components
Fork material
REACTO 400 has a carbon fork, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
As for the wheels, Merida REACTO 400 2018, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The REACTO 400 comes with Rim brakes. Rim brakes deliver an average performance overall. However, they have problems in wet conditions.
