Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset 105, FSA -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Sizing
Recommended size guide.
SM
163cm - 172cm
SM/MD
168cm - 177cm
MD/LG
173cm - 182cm
LG
178cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
REACTO LITE, material: aluminium, 700C wheelsize, 100x9/ 130x9mm axle standard, BSA bottom bracket standard
Suspension Fork
MERIDA REACTO CF
Drivetrain
Rear Derailleur
Shimano 105, GS
Front Derailleur
Shimano 105
Shift Levers
Shimano 105
Cassette
Shimano CS-R7000, 11-30 teeth, 11 speed
Crank
FSA Gossamer Mega, 52-36 teeth, 170 mm-XS/S, 172.5 mm-SM/ML, 175 mm-L/XL
Bottom Bracket
FSA Mega Exo BSA
Chain
KMC X11
Wheels
Front Hub
Road seal bearing, 100x9mm width front hub, 24 spoke holes
Rear Hub
Road seal bearing, 130x9mm width rear hub, 28 spoke holes
Rims
MERIDA COMP CW, 17mm inner width, 30mm height
Spokes
Black stainless
Tires
Maxxis Dolomites, 700x25C, fold
Brakes
Brakes
MERIDA ROAD Pro
Brake Levers
Shimano 105
Cockpit
Handlebar
MERIDA EXPERT CW, material: aluminium
Headset
MERIDA M2331 Neck
Seat
Saddle
MERIDA COMP SL, V-mount
Seatpost
MERIDA COMP CW, material: carbon, Aero shape, 15mm setback
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | SM/MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.35 mm | 1.36 mm | 1.35 mm | 1.39 mm | 1.42 mm | 1.45 mm |
| Bottom Bracket Height | 275 mm | 275 mm | 275 mm | 275 mm | 275 mm | 275 mm |
| Front Center | 577 mm | 581 mm | 587 mm | 597 mm | 607 mm | 622 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 46 mm |
| Trail | 68 mm | 62 mm | 56 mm | 56 mm | 56 mm | 55 mm |
| Stack | 508 mm | 521 mm | 534 mm | 553 mm | 572 mm | 596 mm |
| Reach | 375 mm | 383 mm | 395 mm | 399 mm | 403 mm | 410 mm |
| Top Tube Length | 520 mm | 532 mm | 547 mm | 562 mm | 577 mm | 592 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 470 mm | 500 mm | 520 mm | 540 mm | 560 mm | 590 mm |
| Head Tube Angle | 71 ° | 72 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 120 mm | 130 mm | 140 mm | 160 mm | 180 mm | 205 mm |
| Chainstay Length | 407 mm | 407 mm | 407 mm | 407 mm | 407 mm | 407 mm |
| Wheelbase | 976 mm | 980 mm | 986 mm | 996 mm | 1006 mm | 1021 mm |
| Bottom Bracket Drop | 61 mm | 61 mm | 61 mm | 61 mm | 61 mm | 61 mm |
| Standover Height | 742 mm | 768 mm | 786 mm | 804 mm | 822 mm | 850 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Max Height | 167 cm | 172 cm | 177 cm | 182 cm | 187 cm | cm |
Model Overview
REACTO 400 completes the Merida Reacto model. Merida released 111 bikes variations of this model so far. You can get a glimpse at all models from 2020, by clicking on this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Aero bikes average price
According to our math, the average price for a trustworthy Aero bike is 4211$. However, even if your budget is less than the average, you might still be able to get a top-quality Aero bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Average weight for Aero bikes
Aero bikes weigh an average of 7.34 kg (16.18 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
REACTO 400 weighs 9.4 kg (20.72 lbs) and is much heavier than the average. To sum up, it’s 28.07% heavier than the average weight of Aero bikes.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
The wheels on REACTO 400 are the 700c aluminum type. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Merida REACTO 400 has Rim brakes installed. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, you could spend a little extra and get a bike that has hydraulic brakes.
