Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 700c -
Groupset Ultegra, FSA -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
REACTO CF2
Suspension Fork
Pro Full carbon tapered fork with direct brake mounts
Drivetrain
Rear Derailleur
Shimano Ultegra
Front Derailleur
Shimano Ultegra
Shift Levers
Shimano Ultegra, 22 speed
Cassette
Shimano CS-5800, 11 speed, 11-28 teeth
Crank
FSA Gossamer Pro 52-36 teeth
Chain
KMC X11-1
Wheels
Front Hub
Sealed bearing with quick release
Rear Hub
Sealed bearing with quick release
Rims
MERIDA Expert CW, 35mm profile, 17mm inner width
Spokes
Double Butted Black stainless
Tires
Continental Grand Sport Race 25c folding
Brakes
Brakes
Shimano Ultegra levers with Shimano 105 direct mount calipers
Brake Levers
Shimano Ultegra
Cockpit
Handlebar
MERIDA Expert Aero double butted 6061 aluminium compact drop, oversize clamp
Headset
MERIDA Reacto
Seat
Saddle
MERIDA Race
Seatpost
Reacto carbon Race [Di2 ready]
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | SM/MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.41 mm | 1.41 mm | 1.44 mm | 1.47 mm | 1.5 mm | 1.52 mm |
| Bottom Bracket Height | 266 mm | 266 mm | 266 mm | 270 mm | 270 mm | 270 mm | 270 mm |
| Front Center | 586 mm | 583 mm | 593 mm | 591 mm | 596 mm | 606 mm | 615 mm |
| Rake | 45 mm | 45 mm | 44 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 74 mm | 68 mm | 69 mm | 59 mm | 56 mm | 56 mm | 53 mm |
| Stack | 522 mm | 535 mm | 545 mm | 564 mm | 581 mm | 599 mm | 622 mm |
| Reach | 378 mm | 379 mm | 387 mm | 391 mm | 396 mm | 400 mm | 408 mm |
| Top Tube Length | 521 mm | 526 mm | 541 mm | 551 mm | 566 mm | 581 mm | 596 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 440 mm | 470 mm | 500 mm | 520 mm | 540 mm | 560 mm | 590 mm |
| Head Tube Angle | 70 ° | 71 ° | 71 ° | 72.5 ° | 73 ° | 73 ° | 73.5 ° |
| Head Tube Length | 122 mm | 132 mm | 142 mm | 162 mm | 177 mm | 197 mm | 217 mm |
| Chainstay Length | 414 mm | 414 mm | 414 mm | 414 mm | 414 mm | 414 mm | 414 mm |
| Wheelbase | 990 mm | 987 mm | 997 mm | 996 mm | 1001 mm | 1011 mm | 1020 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 66 mm | 66 mm | 66 mm | 66 mm |
| Standover Height | 718 mm | 741 mm | 765 mm | 788 mm | 808 mm | 827 mm | 854 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
REACTO 5000 completes the Merida Reacto model. Merida released 111 bikes variations of this model so far. You can get a glimpse at all models from 2018, by clicking on this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Aero bikes average price
According to our math, the average price for a trustworthy Aero bike is 4211$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Aero bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Average weight for Aero bikes
On a deeper look, we notice that the average weight of an Aero bike is 7.34 kg (16.18 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
With a weight of 8.41 kg (18.54 lbs), Merida bike is considerably heavier than average. In other words, this model is 14.58% heavier than the average Aero bike.
REACTO 5000 components
Fork material
When it comes to the fork, this bike has a carbon one, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
When it comes to wheels, the REACTO 5000 bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Merida REACTO 5000 is equipped with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they are not nearly as effective as hydraulic brakes are.
