Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 700c -
Groupset Ultegra Di2 -
Suspension Rigid -
Drivetrain 2 × 11 Electronic -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
REACTO CF4
Suspension Fork
MERIDA REACTO CF4
Drivetrain
Rear Derailleur
Shimano Ultegra Di2, SS
Front Derailleur
Shimano Ultegra Di2 DF
Shift Levers
Shimano Ultegra Di2
Cassette
Shimano CS-R8000, 11-28 teeth, 11 speed
Crank
Shimano Ultegra, 52-36 teeth
Chain
KMC X11EL
Wheels
Rims
Vision 55 SC, 100x9mm width front hub, 130x9mm width rear hub, 19mm inner width, 55mm height
Spokes
attached
Tires
Continental Grand Sport Race, 700x25C, fold
Brakes
Brakes
Shimano Ultegra, Direct
Brake Levers
Shimano Ultegra
Cockpit
Handlebar
Vision Metron 6D
Headset
FSA REACTO CF neck, 2191025831
Seat
Saddle
Prologo Zero II pas T2.0
Seatpost
MERIDA Team CW, Aero shape, 15mm setback, Carbon
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | SM/MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.38 mm | 1.39 mm | 1.41 mm | 1.43 mm | 1.45 mm |
| Bottom Bracket Height | 266 mm | 266 mm | 270 mm | 270 mm | 270 mm | 270 mm |
| Front Center | 577 mm | 580 mm | 581 mm | 591 mm | 601 mm | 610 mm |
| Rake | 44 mm | 46 mm | 45 mm | 45 mm | 46 mm | 44 mm |
| Trail | 66 mm | 58 mm | 53 mm | 53 mm | 52 mm | 51 mm |
| Stack | 518 mm | 531 mm | 545 mm | 559 mm | 574 mm | 595 mm |
| Reach | 379 mm | 385 mm | 391 mm | 397 mm | 402 mm | 411 mm |
| Top Tube Length | 522 mm | 537 mm | 547 mm | 562 mm | 577 mm | 592 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 470 mm | 500 mm | 520 mm | 540 mm | 560 mm | 590 mm |
| Head Tube Angle | 71.5 ° | 72.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 74 ° |
| Head Tube Length | 116 mm | 126 mm | 142 mm | 157 mm | 172 mm | 192 mm |
| Chainstay Length | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm |
| Wheelbase | 977 mm | 980 mm | 982 mm | 992 mm | 1002 mm | 1011 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 66 mm | 66 mm | 66 mm | 66 mm |
| Standover Height | 737 mm | 763 mm | 784 mm | 802 mm | 821 mm | 846 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
REACTO 8000-E belongs to the Merida Reacto model. There are 111 bikes that carry this model name. Take a sneak peek at all Merida Reacto bikes models from 2019, by clicking here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Aero bikes
According to our math, the average price for a trustworthy Aero bike is 4211$. However, even if your budget is less than the average, you might still be able to get a top-quality Aero bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Average weight for Aero bikes
The average weight for Aero bikes is 7.34 kg (16.18 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
With a weight of 7.56 kg (16.67 lbs), Merida bike is slightly heavier than average. In short, the average Aero bike weight is 3% lower than this one.
REACTO 8000-E components
Fork material
When it comes to the fork, this bike has a carbon one, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
The wheels on REACTO 8000-E are the 700c carbon type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes deliver an average performance overall. However, they are not nearly as effective as hydraulic brakes are.
