Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra Di2 -
Suspension Rigid -
Drivetrain 2 × 11 Electronic -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Reacto Pro-Direct-E
Suspension Fork
Reacto Carbon Pro-Direct
Drivetrain
Rear Derailleur
Shimano Ultegra SS Di2
Front Derailleur
Shimano Ultegra D Di2
Shift Levers
Shimano Ultegra Di2
Cassette
Shimano CS-6800 11-28 11s
Crank
Shimano Ultegra 50-34
Bottom Bracket
attached
Chain
Shimano 11s
Wheels
Front Hub
attached
Rear Hub
attached
Rims
Fulcrum Quattro
Spokes
attached
Tires
Continental Grand Sport Race 23 fold
Brakes
Brakes
Shimano Ultegra Direct
Brake Levers
attached
Cockpit
Handlebar
FSA Gossamer Compact OS
Headset
Big Conoid-insert carbon Neck CF
Seat
Saddle
ProLogo Zero2
Seatpost
Reacto Aero Carbon Flex
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 50cm | 52cm | 54cm | 56cm | 59cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.39 mm | 1.38 mm | 1.4 mm | 1.45 mm | 1.48 mm |
| Bottom Bracket Height | 275 mm | 275 mm | 275 mm | 275 mm | 275 mm | 275 mm |
| Stack | 516 mm | 529 mm | 542 mm | 561 mm | 580 mm | 604 mm |
| Reach | 373 mm | 381 mm | 392 mm | 402 mm | 400 mm | 408 mm |
| Top Tube Length | 522 mm | 537 mm | 547 mm | 562 mm | 577 mm | 592 mm |
| Seat Tube Angle | 72 ° | 72 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Seat Tube Length | 470 mm | 500 mm | 520 mm | 540 mm | 560 mm | 590 mm |
| Head Tube Angle | 71 ° | 72 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 109 mm | 124 mm | 139 mm | 159 mm | 184 mm | 209 mm |
| Chainstay Length | 407 mm | 407 mm | 407 mm | 407 mm | 407 mm | 407 mm |
| Bottom Bracket Drop | 61 mm | 61 mm | 61 mm | 61 mm | 61 mm | 61 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Reacto CF 907-E belongs to the Merida Reacto model. 111 bikes variations carry this model name so far. Check out the entire range from 2014 of this model, by clicking this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Aero bikes
Our math shows that the average cost of a dependable Aero bike is 4211$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Aero bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Average weight for Aero bikes
Aero bikes have an average weight of 7.34 kg (16.18 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Merida Reacto CF 907-E it’s weighing 7.79 kg (17.17 lbs). At this weight, is a bit heavier than average. In conclusion, the average Aero bike weighs 6.13% less than Reacto CF 907-E.
Reacto CF 907-E components
Fork material
Reacto CF 907-E has a carbon fork, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
The wheels on Reacto CF 907-E are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The Reacto CF 907-E has Rim brakes. Rim brakes deliver an average performance overall. However, they are not nearly as effective as hydraulic brakes are.
