Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
REACTO CF3 IV, material: carbon, 700x30C max. wheelsize, 100x12/ 142x12mm axle standard, BB86,5 bottom bracket standard, MUK 38 (Shimano direct mount)/ MUK 39 Hanger
Suspension Fork
REACTO CF3 IV Disc, material: carbon, 700x30C max. wheelsize
Drivetrain
Rear Derailleur
Shimano 105, GS
Front Derailleur
Shimano 105
Shift Levers
Shimano 105 Disc
Cassette
Shimano CS-R7000, 11-30 teeth, 11 speed
Crank
Shimano 105, 52-36 teeth, 165 mm-XXS/XS, 170 mm-S, 172.5 mm-M, 175 mm-L/XL
Bottom Bracket
SM-BB71-41B, Pressfit 86.5
Chain
KMC X11
Wheels
Front Hub
MERIDA EXPERT SL, including removable lever, 6/4mm allen key
Rear Hub
MERIDA EXPERT SL, including removable lever, 6/4mm allen key
Rims
MERIDA TEAM SL45, 100x12mm width front hub, 142x12mm width rear hub, 19mm inner width, 45mm height, Centerlock, material: carbon
Tires
Continental Ultra Sport III, 700x25C, fold
Brakes
Brakes
Shimano 105, Hydraulic Disc
Brake Levers
Shimano 105
Disk Rotors
Shimano RT54, 160mm
Cockpit
Stem
FSA SMR ACR, material: aluminium, -6° stem angle, 90 mm-XXS/XS, 100 mm-S, 110 mm-M, 120 mm-L/XL
Handlebar
MERIDA EXPERT CW, material: aluminium, 380mm (XXS), 400mm (XS-S), 420mm (M), 440 (L-XL)
Headset
FSA ACR
Seat
Saddle
MERIDA EXPERT SL, V-mount, incl. MERIDA minitool
Seatpost
MERIDA TEAM CW, Aero shape, 15mm setback, Carbon
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.38 mm | 1.39 mm | 1.41 mm | 1.43 mm | 1.45 mm |
| Bottom Bracket Height | 266 mm | 266 mm | 270 mm | 270 mm | 270 mm | 270 mm |
| Front Center | 587 mm | 585 mm | 591 mm | 591 mm | 600 mm | 611 mm |
| Rake | 45 mm | 46 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 71 mm | 61 mm | 59 mm | 53 mm | 53 mm | 50 mm |
| Stack | 519 mm | 531 mm | 544 mm | 559 mm | 573 mm | 595 mm |
| Reach | 379 mm | 386 mm | 392 mm | 397 mm | 402 mm | 411 mm |
| Top Tube Length | 522 mm | 538 mm | 547 mm | 562 mm | 577 mm | 592 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 470 mm | 500 mm | 520 mm | 540 mm | 560 mm | 590 mm |
| Head Tube Angle | 70.5 ° | 72 ° | 72.5 ° | 73.5 ° | 73.5 ° | 74 ° |
| Head Tube Length | 105 mm | 112 mm | 128 mm | 140 mm | 155 mm | 176 mm |
| Chainstay Length | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm |
| Wheelbase | 987 mm | 985 mm | 992 mm | 992 mm | 1001 mm | 1012 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 66 mm | 66 mm | 66 mm | 66 mm |
| Standover Height | 748 mm | 773 mm | 794 mm | 812 mm | 828 mm | 855 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
REACTO LIMITED is part of the Merida Reacto model. There are 111 bikes that carry this model name. Take a sneak peek at all Merida Reacto bikes models from 2022, by clicking here.
Model range prices
The most economical model, the Merida REACTO TRACK 900 2022 has a starting price of 1146$. Merida REACTO TEAM 2022 on the other hand is the most expensive at 10339$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Aero bikes
If you want an acceptable Aero bike you should know that the average price is 4211$. However, you could also get a good Aero bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 3892$. In conclusion, this bike price is 8.2% lower than the price of the average Aero bike.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
When it comes to wheels, the REACTO LIMITED bike is equipped with the 700c carbon model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Merida REACTO LIMITED has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
