Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Rival AXS -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
REACTO CF3 IV, material: carbon, 700x30C max. wheelsize, 100x12/ 142x12 mm axle standard, BB86,5 bottom bracket standard
Suspension Fork
REACTO CF3 IV disc, material: carbon, 700x30C max. wheelsize
Drivetrain
Rear Derailleur
SRAM Rival eTap AXS, SS
Front Derailleur
SRAM Rival eTap AXS
Shift Levers
SRAM Rival eTAP AXS HRD
Cassette
SRAM XG-1250, 10-36 teeth, 12 speed
Crank
SRAM Rival eTap AXS, 48-35 teeth, 165 mm-XXS, 170 mm-XS, 172.5 mm-S/M, 175 mm-L/XL
Bottom Bracket
SRAM Pressfit DUB, Presfit 86.5 mm
Chain
SRAM Rival
Wheels
Rims
DT Swiss P 1800 SPLINE DB 32, 100x12 mm width front hub, 142x12 mm width rear hub, 19 mm inner width, 45 mm height, Centerlock, material: aluminium
Tires
Continental Grand Prix 5000S TR, 700x25C, fold, tubeless ready
Brakes
Brakes
SRAM Rival eTap AXS, Hydraulic disc
Brake Levers
SRAM ED Rival eTap AXS
Cockpit
Handlebar
MERIDA EXPERT CW, material: aluminium, 380 mm (XXS), 400 mm (XS), 420 mm (S/M/L), 440 (XL)
Headset
FSA ACR
Seat
Saddle
MERIDA EXPERT SL, V-mount, incl. MERIDA minitool
Seatpost
MERIDA TEAM CW, Aero shape, 15 mm setback, material: Carbon
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.371 mm | 1.378 mm | 1.39 mm | 1.41 mm | 1.428 mm | 1.45 mm |
| Bottom Bracket Height | 266 mm | 266 mm | 270 mm | 270 mm | 270 mm | 270 mm |
| Front Center | 587 mm | 585 mm | 591 mm | 591 mm | 600 mm | 611 mm |
| Rake | 45 mm | 46 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 71 mm | 61 mm | 59 mm | 53 mm | 53 mm | 50 mm |
| Stack | 517 mm | 529 mm | 542 mm | 557 mm | 571 mm | 593 mm |
| Reach | 377 mm | 384 mm | 390 mm | 395 mm | 400 mm | 409 mm |
| Top Tube Length | 520 mm | 536 mm | 545 mm | 560 mm | 575 mm | 590 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 470 mm | 500 mm | 520 mm | 540 mm | 560 mm | 590 mm |
| Head Tube Angle | 70.5 ° | 72 ° | 72.5 ° | 73.5 ° | 73.5 ° | 74 ° |
| Head Tube Length | 105 mm | 112 mm | 128 mm | 140 mm | 155 mm | 176 mm |
| Chainstay Length | 408 mm | 408 mm | 408 mm | 408 mm | 408 mm | 408 mm |
| Wheelbase | 985 mm | 983 mm | 990 mm | 990 mm | 999 mm | 1010 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 66 mm | 66 mm | 66 mm | 66 mm |
| Standover Height | 746 mm | 771 mm | 792 mm | 810 mm | 826 mm | 853 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
REACTO RIVAL-EDITION is a Merida Reacto model. There are 117 bikes that carry this model name. Take a sneak peek at all Merida Reacto bikes models from 2024, by clicking here.
Model range prices
Merida REACTO 6000 2024 is the most economical model, with a starting price of 2696$. Merida REACTO 9000 2024 on the other hand costs 6420$, and is the most expensive model.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Aero bikes average price
Our math shows that the average cost of a dependable Aero bike is 4211$. However, this doesn’t mean that if you spend less money on an Aero bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
As for the wheels, Merida REACTO RIVAL-EDITION 2024, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Merida REACTO RIVAL-EDITION has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
