Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 700c -
Groupset FSA -
Suspension Rigid -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
REACTO LITE TRACK
Suspension Fork
Full carbon tapered track fork with concealed mounts for a caliper brake
Drivetrain
Cassette
15 tooth freewheel
Crank
FSA Vero Track 46 teeth
Chain
KMC Z610HX
Wheels
Front Hub
Nutted
Rear Hub
Nutted
Rims
MERIDA Expert 35 CW
Spokes
Double Butted Black stainless
Tires
Maxxis Dolomites 23c folding
Cockpit
Handlebar
MERIDA Track Expert with oversize clamp
Headset
MERIDA M2331
Seat
Saddle
MERIDA Race
Seatpost
Reacto carbon
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | SM/MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.26 mm | 1.26 mm | 1.29 mm | 1.31 mm | 1.31 mm | 1.31 mm |
| Bottom Bracket Height | 281 mm | 281 mm | 281 mm | 281 mm | 281 mm | 281 mm |
| Front Center | 561 mm | mm | mm | 572 mm | mm | mm |
| Rake | 30 mm | mm | mm | 25 mm | mm | mm |
| Trail | 84 mm | mm | mm | 77 mm | mm | mm |
| Stack | 481 mm | 494 mm | 512 mm | 526 mm | 540 mm | 555 mm |
| Reach | 383 mm | 391 mm | 396 mm | 402 mm | 413 mm | 423 mm |
| Top Tube Length | 520 mm | 532 mm | 547 mm | 562 mm | 577 mm | 592 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73.5 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 470 mm | 500 mm | 520 mm | 540 mm | 560 mm | 590 mm |
| Head Tube Angle | 71 ° | 72 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 95 mm | 105 mm | 120 mm | 135 mm | 150 mm | 165 mm |
| Chainstay Length | 413 mm | mm | mm | 418 mm | mm | mm |
| Wheelbase | 968 mm | 972 mm | 973 mm | 984 mm | 999 mm | 1014 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 55 mm | 55 mm | 55 mm | 55 mm |
| Standover Height | 741 mm | 766 mm | 785 mm | 802 mm | 820 mm | 845 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
REACTO TRACK 500 belongs to the Merida Reacto model. Merida released 111 bikes variations of this model so far. Check out the entire range from 2018 of this model, by clicking this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Aero bikes
If you want to purchase a solid Aero bike, it is important to know that the average cost is 4211$. However, this doesn’t mean that if you spend less money on an Aero bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Aero bikes average weight
Aero bikes have an average weight of 7.34 kg (16.18 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
slightly heavier than average, REACTO TRACK 500 has a weight of 7.53 kg (16.6 lbs). In conclusion, the average Aero bike weighs 2.59% less than REACTO TRACK 500.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
As for the wheels, Merida REACTO TRACK 500 2018, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The REACTO TRACK 500 has Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they are not nearly as effective as hydraulic brakes are.
