Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 700c -
Groupset Tiagra -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
RIDE LITE
Suspension Fork
Road carbon comp
Drivetrain
Rear Derailleur
Shimano TIAGRA GS
Front Derailleur
Shimano TIAGRA D
Shift Levers
Shimano Tiagra
Cassette
Shimano CS-HG500-10 11-32
Crank
Shimano TIAGRA 50-34 (BSA)
Bottom Bracket
BSA, 68mm, threaded
Chain
KMC X10
Wheels
Rims
Shimano R501
Tires
Maxxis Detonator 25 fold
Brakes
Brakes
Merida Road Comp
Brake Levers
Shimano Tiagra
Cockpit
Handlebar
MERIDA Compact road OS
Headset
FSA BB410P/No.55E
Seat
Saddle
MERIDA Race 5
Seatpost
MERIDA carbon H SB15 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 44cm | 47cm | 50cm | 52cm | 54cm | 56cm | 59cm | 62cm |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.54 mm | 1.57 mm | 1.57 mm | 1.57 mm | 1.6 mm | 1.62 mm | 1.64 mm | 1.62 mm |
| Bottom Bracket Height | 271 mm | 271 mm | 271 mm | 271 mm | 271 mm | 271 mm | 271 mm | 271 mm |
| Front Center | 588 mm | 589 mm | 587 mm | 587 mm | 587 mm | 596 mm | 611 mm | 636 mm |
| Rake | 73 mm | 71 mm | 66 mm | 61 mm | 53 mm | 45 mm | 43 mm | 46 mm |
| Trail | 40 mm | 42 mm | 41 mm | 43 mm | 48 mm | 57 mm | 59 mm | 56 mm |
| Stack | 542 mm | 552 mm | 565 mm | 576 mm | 597 mm | 621 mm | 645 mm | 664 mm |
| Reach | 351 mm | 351 mm | 359 mm | 366 mm | 373 mm | 383 mm | 393 mm | 409 mm |
| Top Tube Length | 524 mm | 524 mm | 536 mm | 546 mm | 556 mm | 571 mm | 586 mm | 611 mm |
| Seat Tube Angle | 75 ° | 75 ° | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 440 mm | 470 mm | 500 mm | 520 mm | 540 mm | 560 mm | 590 mm | 620 mm |
| Head Tube Angle | 71 ° | 71 ° | 72 ° | 72.5 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 140 mm | 150 mm | 160 mm | 170 mm | 190 mm | 215 mm | 240 mm | 260 mm |
| Chainstay Length | 416 mm | 416 mm | 416 mm | 416 mm | 416 mm | 416 mm | 416 mm | 416 mm |
| Wheelbase | 995 mm | 996 mm | 994 mm | 994 mm | 994 mm | 1003 mm | 1018 mm | 1043 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 712 mm | 736 mm | 761 mm | 778 mm | 797 mm | 817 mm | 845 mm | 872 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
RIDE 300 completes the Merida Ride model. 74 bikes variations carry this model name so far. You can get a glimpse at all models from 2016, by clicking on this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Endurance bikes average price
According to our math, the average price for a trustworthy Endurance bike is 2346$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Endurance bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Average weight for Endurance bikes
Endurance bikes have an average weight of 8.2 kg (18.08 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
Weighing 9.2 kg (20.28 lbs), the RIDE 300 model is considerably heavier than average. In other words, this model is 12.2% heavier than the average Endurance bike.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
When leaving the production line, the RIDE 300 model has 700c aluminum wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they have problems in wet conditions.
