Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 700c -
Groupset 105, Shimano -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
RIDE CF2
Suspension Fork
Road carbon Race
Drivetrain
Rear Derailleur
Shimano 105 GS
Front Derailleur
Shimano 105 D
Shift Levers
Shimano 105
Cassette
Shimano CS-5800-11 11-32
Crank
Shimano RS500 50-34
Bottom Bracket
attached
Chain
FSA F11S
Wheels
Front Hub
attached
Rear Hub
attached
Rims
Fulcrum Racing Sport
Tires
Continental Ultra Sport II 25 fold
Brakes
Brakes
Merida Road Pro
Brake Levers
attached
Cockpit
Handlebar
Controltech ONE Road
Headset
Big Conoid S-bearing neck pro
Seat
Saddle
MERIDA Race 5
Seatpost
Controltech T5 SB10 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 50cm | 52cm | 54cm | 56cm | 59cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.453 mm | 1.476 mm | 1.5 mm | 1.561 mm | 1.616 mm | 1.645 mm |
| Bottom Bracket Height | 271 mm | 271 mm | 271 mm | 271 mm | 271 mm | 271 mm |
| Front Center | 588 mm | 586 mm | 587 mm | 587 mm | 596 mm | 611 mm |
| Rake | 44 mm | 45 mm | 45 mm | 46 mm | 45 mm | 45 mm |
| Trail | 70 mm | 63 mm | 60 mm | 56 mm | 57 mm | 57 mm |
| Stack | 542 mm | 555 mm | 567 mm | 587 mm | 611 mm | 635 mm |
| Reach | 373 mm | 376 mm | 378 mm | 376 mm | 378 mm | 386 mm |
| Top Tube Length | 518 mm | 530 mm | 540 mm | 550 mm | 565 mm | 580 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Head Tube Angle | 71 ° | 72 ° | 72.5 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 150 mm | 160 mm | 170 mm | 190 mm | 215 mm | 240 mm |
| Chainstay Length | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm |
| Wheelbase | 989 mm | 987 mm | 988 mm | 988 mm | 997 mm | 1012 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 793 mm | 814 mm | 833 mm | 852 mm | 873 mm | 901 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Ride 4000 completes the Merida Ride model. There are 74 bikes that carry this model name. Take a sneak peek at all Merida Ride bikes models from 2015, by clicking here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Endurance bikes average price
If you want to purchase a solid Endurance bike, it is important to know that the average cost is 2346$. However, you could also get a good Endurance bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Ride 4000 components
Fork material
When it comes to the fork, this bike has a carbon one, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
The wheels on Ride 4000 are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Merida Ride 4000 is equipped with Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they are not nearly as effective as hydraulic brakes are.
