Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 700c -
Groupset 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
RIDE CF2
Suspension Fork
Road carbon Race
Drivetrain
Rear Derailleur
Shimano 105 GS
Front Derailleur
Shimano 105 D
Shift Levers
Shimano 105
Cassette
Shimano CS-5800-11 11-32
Crank
Shimano 105 50-34 [BSA]
Bottom Bracket
BSA, 68mm, threaded
Chain
KMC X11
Wheels
Front Hub
attached
Rear Hub
attached
Rims
Shimano RS10
Spokes
attached
Tires
Continental Ultra Sport II 25 fold
Brakes
Brakes
MERIDA Road Pro
Brake Levers
Shimano 105
Cockpit
Handlebar
MERIDA Expert Compact road OS
Headset
Big Conoid S-bearing neck pro
Seat
Saddle
MERIDA Race
Seatpost
MERIDA carbon Expert SB15 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 44cm | 47cm | 50cm | 52cm | 54cm | 56cm | 59cm | 62cm |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.45 mm | 1.47 mm | 1.49 mm | 1.55 mm | 1.61 mm | 1.64 mm | 1.61 mm |
| Bottom Bracket Height | 271 mm | 271 mm | 271 mm | 271 mm | 271 mm | 271 mm | 271 mm | 271 mm |
| Front Center | 588 mm | 588 mm | 586 mm | 587 mm | 587 mm | 596 mm | 611 mm | 636 mm |
| Rake | 44 mm | 44 mm | 45 mm | 45 mm | 46 mm | 45 mm | 45 mm | 45 mm |
| Trail | 70 mm | 70 mm | 63 mm | 60 mm | 56 mm | 57 mm | 57 mm | 57 mm |
| Stack | 548 mm | 548 mm | 561 mm | 573 mm | 593 mm | 617 mm | 641 mm | 660 mm |
| Reach | 379 mm | 379 mm | 382 mm | 384 mm | 382 mm | 384 mm | 392 mm | 411 mm |
| Top Tube Length | 524 mm | 524 mm | 536 mm | 546 mm | 556 mm | 571 mm | 586 mm | 611 mm |
| Seat Tube Angle | 75 ° | 75 ° | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 440 mm | 470 mm | 500 mm | 520 mm | 540 mm | 560 mm | 590 mm | 620 mm |
| Head Tube Angle | 71 ° | 71 ° | 72 ° | 72.5 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 150 mm | 150 mm | 160 mm | 170 mm | 190 mm | 215 mm | 240 mm | 260 mm |
| Chainstay Length | 416 mm | 416 mm | 416 mm | 416 mm | 416 mm | 416 mm | 416 mm | 416 mm |
| Wheelbase | 995 mm | 995 mm | 993 mm | 994 mm | 994 mm | 1003 mm | 1018 mm | 1043 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 712 mm | 735 mm | 757 mm | 775 mm | 794 mm | 815 mm | 843 mm | 869 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
RIDE 4000 belongs to the Merida Ride model. There are 74 bikes that carry this model name. You can easily view all of the Merida Ride bikes models from 2017, here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Endurance bikes average price
If you want to purchase a solid Endurance bike, it is important to know that the average cost is 2346$. However, even though the average price of an Endurance bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Endurance bikes average weight
Endurance bikes weigh an average of 8.2 kg (18.08 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
With a weight of 8.45 kg (18.63 lbs), Merida bike is slightly heavier than average. In other words, this model is 3.05% heavier than the average Endurance bike.
RIDE 4000 components
Fork material
When it comes to the fork, this bike has a carbon one, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
When leaving the production line, the RIDE 4000 model has 700c aluminum wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The RIDE 4000 has Rim brakes. Rim brakes deliver an average performance overall. However, you could spend a little extra and get a bike that has hydraulic brakes.
