Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 700c -
Groupset Ultegra, Shimano -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
RIDE CF3
Suspension Fork
Ride Carbon Superlite flex
Drivetrain
Rear Derailleur
Shimano Ultegra GS
Front Derailleur
Shimano Ultegra D
Shift Levers
Shimano Ultegra
Cassette
Shimano CS-5800-11 11-32
Crank
Shimano RS500 50-34 (BB386)
Bottom Bracket
BB86/BB92, press-fit
Chain
KMC X11
Wheels
Rims
Fulcrum Racing 7
Tires
Continental Grand Sport Race 25 fold
Brakes
Brakes
Shimano R561
Brake Levers
Shimano Ultegra
Cockpit
Handlebar
FSA Gossamer compact OS
Headset
FSA BB410P/No.55E
Seat
Saddle
Prologo Kappa 3
Seatpost
MERIDA carbon H SB15 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 50cm | 52cm | 54cm | 56cm | 59cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.58 mm | 1.43 mm | 1.49 mm | 1.51 mm | 1.56 mm | 1.6 mm |
| Bottom Bracket Height | 268 mm | 268 mm | 268 mm | 268 mm | 268 mm | 268 mm |
| Front Center | 576 mm | 583 mm | 584 mm | 589 mm | 599 mm | 615 mm |
| Rake | 32 mm | 48 mm | 48 mm | 46 mm | 48 mm | 56 mm |
| Trail | 80 mm | 60 mm | 57 mm | 56 mm | 53 mm | 42 mm |
| Stack | 583 mm | 539 mm | 560 mm | 578 mm | 600 mm | 626 mm |
| Reach | 368 mm | 378 mm | 377 mm | 383 mm | 384 mm | 391 mm |
| Top Tube Length | 520 mm | 532 mm | 542 mm | 552 mm | 567 mm | 582 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 470 mm | 500 mm | 520 mm | 540 mm | 560 mm | 590 mm |
| Head Tube Angle | 71.5 ° | 72 ° | 72.5 ° | 73 ° | 73 ° | 73.5 ° |
| Head Tube Length | 130 mm | 135 mm | 155 mm | 172 mm | 195 mm | 220 mm |
| Chainstay Length | 412 mm | 412 mm | 412 mm | 415 mm | 415 mm | 415 mm |
| Wheelbase | 978 mm | 985 mm | 986 mm | 994 mm | 1004 mm | 1021 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Standover Height | 793 mm | 816 mm | 835 mm | 835 mm | 874 mm | 903 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
RIDE 5000 SE is part of the Merida Ride model. 74 bikes variations carry this model name so far. Take a sneak peek at all Merida Ride bikes models from 2016, by clicking here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Endurance bikes
According to our math, the average price for a trustworthy Endurance bike is 2346$. However, even if your budget is less than the average, you might still be able to get a top-quality Endurance bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Endurance bikes average weight
The average weight for Endurance bikes is 8.2 kg (18.08 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Weighing 8.2 kg (18.08 lbs), the RIDE 5000 SE model is equally heavier with average. To sum up, it’s 0% heavier than the average weight of Endurance bikes.
RIDE 5000 SE components
Fork material
The fork is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
When it comes to wheels, the RIDE 5000 SE bike is equipped with the 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The RIDE 5000 SE has Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they are not nearly as effective as hydraulic brakes are.
