Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 700c -
Groupset Tiagra, FSA -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
RIDE DISC CF2
Suspension Fork
Race carbon disc 15
Drivetrain
Rear Derailleur
Shimano TIAGRA GS
Front Derailleur
Shimano TIAGRA D
Shift Levers
Shimano Tiagra
Cassette
Shimano CS-HG500-10 11-32
Crank
FSA Gossamer Pro 50-34 (BB86)
Bottom Bracket
BB86/BB92, press-fit
Chain
KMC X10
Wheels
Front Hub
Bearing Disc-15 Road Axle / Bearing Disc cassette
Rear Hub
Bearing Disc-15 Road Axle / Bearing Disc cassette
Rims
MERIDA comp 22 disc pair
Spokes
Black stainless
Tires
Maxxis Detonator 25 fold
Brakes
Brakes
Tektro Spyre disc 160
Brake Levers
Shimano Tiagra
Cockpit
Handlebar
MERIDA Compact road OS
Headset
FSA BB410P/No.55E
Seat
Saddle
MERIDA Race 5
Seatpost
MERIDA carbon H SB15 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 50cm | 52cm | 54cm | 56cm | 59cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.48 mm | 1.51 mm | 1.55 mm | 1.55 mm | 1.58 mm |
| Bottom Bracket Height | 267 mm | 267 mm | 267 mm | 267 mm | 267 mm | 267 mm |
| Front Center | 569 mm | 572 mm | 579 mm | 586 mm | 602 mm | 617 mm |
| Rake | 37 mm | 33 mm | 38 mm | 35 mm | 38 mm | 37 mm |
| Trail | 78 mm | 75 mm | 67 mm | 67 mm | 64 mm | 65 mm |
| Stack | 543 mm | 558 mm | 572 mm | 598 mm | 612 mm | 636 mm |
| Reach | 365 mm | 377 mm | 379 mm | 386 mm | 395 mm | 403 mm |
| Top Tube Length | 520 mm | 532 mm | 544 mm | 556 mm | 572 mm | 587 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 470 mm | 500 mm | 520 mm | 540 mm | 560 mm | 590 mm |
| Head Tube Angle | 71 ° | 72 ° | 72.5 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 140 mm | 152 mm | 165 mm | 180 mm | 205 mm | 230 mm |
| Chainstay Length | 414 mm | 414 mm | 414 mm | 414 mm | 414 mm | 414 mm |
| Wheelbase | 973 mm | 976 mm | 983 mm | 990 mm | 1006 mm | 1021 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm |
| Standover Height | 786 mm | 811 mm | 830 mm | 849 mm | 870 mm | 899 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
RIDE DISC 3000 belongs to the Merida Ride model. There are 74 bikes that carry this model name. Take a sneak peek at all Merida Ride bikes models from 2016, by clicking here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Endurance bikes average price
According to our calculations, the average cost of an Endurance bike that is reliable is 2346$. However, this doesn’t mean that if you spend less money on an Endurance bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Average weight for Endurance bikes
The average weight for Endurance bikes is 8.2 kg (18.08 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
considerably heavier than average, RIDE DISC 3000 has a weight of 9.1 kg (20.06 lbs). In other words, this model is 10.98% heavier than the average Endurance bike.
Overview of components
Fork material
RIDE DISC 3000 has a carbon fork, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
The RIDE DISC 3000 2016 bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The RIDE DISC 3000 comes with Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
