Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Dura-Ace Di2 -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SCULTURA CF5 V, material: carbon, 700x30C max. wheelsize, 100x12/ 142x12mm axle standard, Pressfit 86,5, MUK 38 (Shimano direct mount)/ MUK 39 Hanger
Suspension Fork
SCULTURA CF5 Disc, material: carbon, 700x30C max. wheelsize
Drivetrain
Rear Derailleur
Shimano Dura Ace Di2
Front Derailleur
Shimano Dura Ace Di2
Shift Levers
Shimano Dura Ace Disc Di2
Cassette
Shimano CS-R9200, 11-30 teeth, 12 speed
Crank
Shimano Dura Ace, 52-36 teeth, Power Meter, 165 mm-XXS/XS, 170 mm-S, 172.5 mm-M, 175 mm-L/XL
Bottom Bracket
SM-BB92-41B, Pressfit 86.5
Chain
Shimano CN-M9100-12
Wheels
Front Hub
MERIDA EXPERT SL, including removable lever, 6/4mm allen key
Rear Hub
MERIDA EXPERT SL, including removable lever, 6/4mm allen key
Rims
ZIPP 353 NSW TL Disc, 100x12mm width front hub, 142x12mm width rear hub, 25mm inner width, 45mm height, Centerlock, material: carbon, Tubeless ready (tubeless tape and valves included)
Tires
Continental Grand Prix 5000S TR, 700x28C, fold, tubeless ready
Brakes
Brakes
Shimano Dura Ace, Hydraulic Disc
Brake Levers
Shimano Dura Ace Disc
Disk Rotors
Shimano MT900, 160mm, 140mm
Cockpit
Stem
MERIDA TEAM ONE-PIECE INTEGRATED, material: carbon, 90 mm-XXS/XS, 100 mm-S, 110 mm-M, 120 mm-L/XL
Handlebar
MERIDA TEAM SL 1P INTEGRATED, material: carbon, 400mm (XXS-XS-S), 420mm (M), 440mm (L-XL)
Headset
MERIDA TEAM SL, OP-203 neck
Seat
Saddle
Prologo Scratch M5
Seatpost
MERIDA TEAM SL, 27.2mm diameter, 15mm setback, Carbon, S-Flex
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.38 mm | 1.4 mm | 1.42 mm | 1.44 mm |
| Bottom Bracket Height | 266 mm | 270 mm | 270 mm | 270 mm | 270 mm |
| Front Center | 584 mm | 590 mm | 591 mm | 601 mm | 611 mm |
| Rake | 46 mm | 44 mm | 45 mm | 46 mm | 45 mm |
| Trail | 61 mm | 60 mm | 53 mm | 52 mm | 50 mm |
| Stack | 536 mm | 549 mm | 564 mm | 578 mm | 600 mm |
| Reach | 390 mm | 397 mm | 402 mm | 407 mm | 416 mm |
| Top Tube Length | 542 mm | 552 mm | 567 mm | 582 mm | 597 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 458 mm | 481 mm | 501 mm | 521 mm | 550 mm |
| Head Tube Angle | 72 ° | 72.5 ° | 73.5 ° | 73.5 ° | 74 ° |
| Head Tube Length | 112 mm | 128 mm | 140 mm | 155 mm | 176 mm |
| Chainstay Length | 415 mm | 415 mm | 415 mm | 415 mm | 415 mm |
| Wheelbase | 989 mm | 996 mm | 997 mm | 1007 mm | 1017 mm |
| Bottom Bracket Drop | 70 mm | 66 mm | 66 mm | 66 mm | 66 mm |
| Standover Height | 752 mm | 772 mm | 789 mm | 807 mm | 830 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
SCULTURA 10K belongs to the Merida Scultura model. There are 214 bikes that carry this model name. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
Merida SCULTURA RIM 100 2022 is the cheapest bike model and costs 1077$. Merida SCULTURA 10K 2022 is the most expensive one and costs 12164$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Race bikes
If you want an acceptable Race bike you should know that the average price is 3350$. However, this doesn’t mean that if you spend less money on a Race bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When Merida released this model in 2022, its price was 12164$. If we compare this with the average Race bike cost we notice that the price is 263.1% higher.
Overview of components
Fork material
SCULTURA 10K has a carbon fork, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
As for the wheels, Merida SCULTURA 10K 2022, has a 700c carbon model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
