Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Tiagra, Shimano -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SCULTURA Disc LITE, material: aluminium, 700x28C max. wheelsize, 100x12/ 142x12mm axle standard, Pressfit bottom bracket standard
Suspension Fork
SCULTURA CF2 Disc, 700x28C max. wheelsize
Drivetrain
Rear Derailleur
Shimano Tiagra, GS
Front Derailleur
Shimano Tiagra
Shift Levers
Shimano Tiaga Disc
Cassette
Shimano CS-HG500, 12-28 teeth, 10 speed
Crank
Shimano Tiagra, 50-34 teeth, 165 mm-XXS, 170 mm-XS/S, 172.5 mm-SM/ML, 175 mm-L/XL
Bottom Bracket
BSA, 100mm, threaded
Chain
KMC X10
Wheels
Front Hub
VP CLK170F, 100x12mm width front hub, 28 spoke holes, Centerlock
Rear Hub
VP CLK270R, 142x12mm width rear hub, 28 spoke holes, Centerlock
Rims
MERIDA EXPERT SL, 17mm inner width, 22mm height, material: aluminium
Spokes
Black stainless
Tires
Maxxis Pursuer, 700x25C, fold
Brakes
Brakes
Shimano Tiagra, Hydraulic Disc
Brake Levers
Shimano Tiagra
Cockpit
Handlebar
MERIDA EXPERT SL, material: aluminium, 380mm(XXS), 400mm (XS-S), 420mm (M), 440mm (L-XL)
Headset
MERIDA M2339
Seat
Saddle
MERIDA COMP SL, V-mount
Seatpost
MERIDA COMP CC, material: aluminium, 27.2mm diameter, 5mm setback
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXXS | XXS | XS | SM | SM/MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.39 mm | 1.43 mm | 1.45 mm | 1.45 mm | 1.48 mm | 1.51 mm | 1.55 mm |
| Bottom Bracket Height | 266 mm | 270 mm | 270 mm | 270 mm | 270 mm | 270 mm | 270 mm | 270 mm |
| Front Center | 580 mm | 583 mm | 584 mm | 580 mm | 586 mm | 596 mm | 606 mm | 615 mm |
| Rake | 55 mm | 45 mm | 45 mm | 44 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 61 mm | 68 mm | 68 mm | 63 mm | 56 mm | 56 mm | 56 mm | 53 mm |
| Stack | 491 mm | 512 mm | 522 mm | 535 mm | 548 mm | 567 mm | 586 mm | 612 mm |
| Reach | 359 mm | 369 mm | 366 mm | 368 mm | 379 mm | 383 mm | 387 mm | 394 mm |
| Top Tube Length | 493 mm | 508 mm | 513 mm | 523 mm | 538 mm | 553 mm | 568 mm | 583 mm |
| Seat Tube Angle | 75 ° | 75 ° | 74.5 ° | 74 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 410 mm | 440 mm | 470 mm | 500 mm | 520 mm | 540 mm | 560 mm | 590 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 71 ° | 72 ° | 73 ° | 73 ° | 73 ° | 73.5 ° |
| Head Tube Length | 100 mm | 120 mm | 130 mm | 140 mm | 150 mm | 170 mm | 190 mm | 215 mm |
| Chainstay Length | 401 mm | 401 mm | 401 mm | 401 mm | 401 mm | 401 mm | 401 mm | 401 mm |
| Wheelbase | 971 mm | 975 mm | 976 mm | 972 mm | 978 mm | 988 mm | 998 mm | 1007 mm |
| Bottom Bracket Drop | 70 mm | 66 mm | 66 mm | 66 mm | 66 mm | 66 mm | 66 mm | 66 mm |
| Standover Height | 661 mm | 690 mm | 713 mm | 737 mm | 755 mm | 772 mm | 791 mm | 819 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
SCULTURA 300 belongs to the Merida Scultura model. Merida released 214 bikes variations of this model so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
The most economical model, the Merida SCULTURA RIM 100 2023 has a starting price of 1077$. Merida SCULTURA 10K 2023 on the other hand is the most expensive at 12164$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Race bikes average price
According to our calculations, the average cost of a Race bike that is reliable is 3350$. However, this doesn’t mean that if you spend less money on a Race bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, Merida SCULTURA 300 price was 1273$. Comparing the average cost of a Race bike to this one, you will see that SCULTURA 300 price is 163.16% smaller.
SCULTURA 300 components
Fork material
The fork on this bike is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The wheels on SCULTURA 300 are the 700c aluminum type. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Merida SCULTURA 300 has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
