Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra Di2 -
Suspension Rigid -
Drivetrain 2 × 11 Electronic -
Brakes Rim
Sizing
Recommended size guide.
XS
158cm - 167cm
SM
163cm - 172cm
SM/MD
168cm - 177cm
MD/LG
173cm - 182cm
LG
178cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SCULTURA CF4, material: carbon, 700C wheelsize, 100x9/ 130x9mm axle standard, BB386-PF30 bottom bracket standard
Suspension Fork
SCULTURA CF4
Drivetrain
Rear Derailleur
Shimano Ultegra Di2, GS
Front Derailleur
Shimano Ultegra Di2
Shift Levers
Shimano Ultegra Di2
Cassette
Shimano CS-R8000, 11-30 teeth, 11 speed
Crank
Shimano Ultegra, 52-36 teeth, 165 mm-XXS, 170 mm-XS/S, 172.5 mm-SM/ML, 175 mm-L/XL
Bottom Bracket
FSA 386-BB30 PF6000 [SMN FC]
Chain
KMC X11EL
Wheels
Rims
Vision 40 SC, 100x9mm width front hub, 130x9mm width rear hub, 19mm inner width, 40mm height
Tires
Continental Grand Sport Race, 700x25C, fold
Brakes
Brakes
Shimano Ultegra
Brake Levers
Shimano Ultegra
Cockpit
Handlebar
MERIDA TEAM SL, material: carbon
Headset
FSA NO.44/CF neck
Seat
Saddle
Prologo Scratch 2
Seatpost
MERIDA TEAM SL, material: carbon, 27.2mm diameter, 15mm setback, S-Flex
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | SM/MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.34 mm | 1.35 mm | 1.36 mm | 1.39 mm | 1.41 mm | 1.42 mm | 1.44 mm |
| Bottom Bracket Height | 270 mm | 270 mm | 270 mm | 270 mm | 270 mm | 270 mm | 270 mm |
| Front Center | 572 mm | 578 mm | 580 mm | 581 mm | 591 mm | 600 mm | 610 mm |
| Rake | 45 mm | 46 mm | 47 mm | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 68 mm | 64 mm | 57 mm | 52 mm | 52 mm | 52 mm | 48 mm |
| Stack | 506 mm | 518 mm | 530 mm | 549 mm | 563 mm | 577 mm | 598 mm |
| Reach | 377 mm | 383 mm | 389 mm | 394 mm | 400 mm | 405 mm | 414 mm |
| Top Tube Length | 516 mm | 526 mm | 541 mm | 551 mm | 566 mm | 581 mm | 596 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 440 mm | 470 mm | 500 mm | 520 mm | 540 mm | 560 mm | 590 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 74 ° |
| Head Tube Length | 105 mm | 115 mm | 125 mm | 140 mm | 155 mm | 170 mm | 190 mm |
| Chainstay Length | 406 mm | 406 mm | 406 mm | 406 mm | 406 mm | 406 mm | 406 mm |
| Wheelbase | 969 mm | 975 mm | 977 mm | 978 mm | 988 mm | 997 mm | 1007 mm |
| Bottom Bracket Drop | 66 mm | 66 mm | 66 mm | 66 mm | 66 mm | 66 mm | 66 mm |
| Standover Height | 697 mm | 724 mm | 750 mm | 770 mm | 785 mm | 804 mm | 831 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Max Height | 162 cm | 167 cm | 172 cm | 177 cm | 182 cm | 187 cm | cm |
Model Overview
SCULTURA 8000-E is part of the Merida Scultura model. There are 214 bikes that carry this model name. You can get a glimpse at all models from 2020, by clicking on this link.
Model range prices
Merida SCULTURA 100 2020 is the cheapest bike model and costs 912$. Merida SCULTURA DISC 9000-E 2020 is the most expensive one and costs 9427$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Race bikes
According to our calculations, the average cost of a Race bike that is reliable is 3350$. However, even if your budget is less than the average, you might still be able to get a top-quality Race bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Average weight for Race bikes
Race bikes weigh an average of 6.82 kg (15.04 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
SCULTURA 8000-E weighs 6.91 kg (15.23 lbs) and is slightly heavier than the average. To sum up, it’s 1.32% heavier than the average weight of Race bikes.
SCULTURA 8000-E components
Fork material
When it comes to the fork, this bike has a carbon one, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
When leaving the production line, the SCULTURA 8000-E model has 700c carbon wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Merida SCULTURA 8000-E is equipped with Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, you could spend a little extra and get a bike that has hydraulic brakes.
