Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Athena -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Scultura Comp-E
Suspension Fork
Scultura Carbon Lite
Drivetrain
Rear Derailleur
Campagnolo Athena
Front Derailleur
Campagnolo Athena
Shift Levers
Campagnolo Athena carbon
Cassette
Campagnolo 11s 12-27
Crank
Campagnolo Athena 50-34
Bottom Bracket
Campagnolo BB
Chain
Campagnolo Chorus 11s
Wheels
Front Hub
attached
Rear Hub
attached
Rims
Campagnolo Khamsin
Spokes
attached
Tires
Continental Ultra Sport II 23 fold
Brakes
Brakes
Campagnolo Athena
Brake Levers
attached
Cockpit
Handlebar
FSA Gossamer Ergo OS
Headset
Big Conoid A-Bearing Neck Pro
Seat
Saddle
ProLogo kappa Evo
Seatpost
Merida Carbon H SB15 27.2 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 44cm | 47cm | 50cm | 52cm | 54cm | 56cm | 59cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.34 mm | 1.43 mm | 1.44 mm | 1.43 mm | 1.46 mm | 1.5 mm | 1.53 mm |
| Bottom Bracket Height | 270 mm | 270 mm | 270 mm | 270 mm | 270 mm | 270 mm | 270 mm |
| Stack | 515 mm | 534 mm | 547 mm | 560 mm | 577 mm | 598 mm | 624 mm |
| Reach | 385 mm | 373 mm | 381 mm | 392 mm | 396 mm | 400 mm | 407 mm |
| Top Tube Length | 521 mm | 524 mm | 536 mm | 551 mm | 566 mm | 581 mm | 596 mm |
| Seat Tube Angle | 75 ° | 74 ° | 74 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 440 mm | 475 mm | 500 mm | 520 mm | 540 mm | 560 mm | 590 mm |
| Head Tube Angle | 71 ° | 71 ° | 72 ° | 73 ° | 73 ° | 73 ° | 73.5 ° |
| Head Tube Length | 110 mm | 130 mm | 140 mm | 150 mm | 170 mm | 190 mm | 215 mm |
| Chainstay Length | 414 mm | 414 mm | 414 mm | 414 mm | 414 mm | 414 mm | 414 mm |
| Bottom Bracket Drop | 66 mm | 66 mm | 66 mm | 66 mm | 66 mm | 66 mm | 66 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Scultura CF 906-C is part of the Merida Scultura model. Merida launched 214 bikes of this model so far. Take a sneak peek at all Merida Scultura bikes models from 2014, by clicking here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Race bikes
If you want to purchase a solid Race bike, it is important to know that the average cost is 3350$. However, even if your budget is less than the average, you might still be able to get a top-quality Race bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Average weight for Race bikes
Race bikes have an average weight of 6.82 kg (15.04 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
With a weight of 7.91 kg (17.44 lbs), Merida bike is much heavier than average. To sum up, it’s 15.98% heavier than the average weight of Race bikes.
Overview of components
Fork material
The fork is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
When leaving the production line, the Scultura CF 906-C model has 700c aluminum wheels. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Scultura CF 906-C comes with Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they have problems in wet conditions.
