Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 700c -
Groupset 105, Shimano -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SCULTURA DISC CF2 JULIET
Suspension Fork
Pro full carbon tapered fork with 12mm through axle and disc mounts
Drivetrain
Rear Derailleur
Shimano 105
Front Derailleur
Shimano 105
Shift Levers
Shimano RS505 disc, 22 speed
Cassette
Shimano CS-5800, 11 speed, 11-28
Crank
Shimano 105 50-34 teeth
Chain
KMC X11-1
Wheels
Front Hub
Sealed bearing, centerlock, 12mm through axles
Rear Hub
Sealed bearing, centerlock, 12mm through axles
Rims
MERIDA Expert SL - 22mm profile, 17mm inner width, Disc only
Spokes
Double Butted Black stainless
Tires
Continental Ultra Sport II 28c folding
Brakes
Brakes
Shimano RS505 hydraulic disc brakes with 160mm rotors
Brake Levers
Shimano 105
Cockpit
Handlebar
MERIDA Expert double butted 6061 aluminium compact drop, oversize clamp
Headset
MERIDA M2331
Seat
Saddle
Female specific Juliet Sport
Seatpost
MERIDA Carbon Comp 15mm, 27.2mm offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | SM/MD |
|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.41 mm | 1.44 mm | 1.43 mm |
| Bottom Bracket Height | 270 mm | 270 mm | 270 mm | 270 mm |
| Front Center | 583 mm | 584 mm | 580 mm | 586 mm |
| Rake | 53 mm | 45 mm | 44 mm | 45 mm |
| Trail | 60 mm | 68 mm | 63 mm | 56 mm |
| Stack | 525 mm | 535 mm | 548 mm | 561 mm |
| Reach | 373 mm | 379 mm | 381 mm | 392 mm |
| Top Tube Length | 521 mm | 526 mm | 536 mm | 551 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 74 ° |
| Seat Tube Length | 440 mm | 470 mm | 500 mm | 520 mm |
| Head Tube Angle | 71 ° | 71 ° | 72 ° | 73 ° |
| Head Tube Length | 120 mm | 130 mm | 140 mm | 150 mm |
| Chainstay Length | 414 mm | 414 mm | 414 mm | 414 mm |
| Wheelbase | 988 mm | 989 mm | 985 mm | 991 mm |
| Bottom Bracket Drop | 66 mm | 66 mm | 66 mm | 66 mm |
| Standover Height | 705 mm | 723 mm | 753 mm | 772 mm |
| Wheels | 700 | 700 | 700 | 700 |
Model Overview
SCULTURA DISC 4000 JULIET is a Merida Scultura model. There are 214 bikes that carry this model name. You can get a glimpse at all models from 2018, by clicking on this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Race bikes
According to our math, the average price for a trustworthy Race bike is 3350$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Race bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Average weight for Race bikes
If we make a quick analysis of the average weight of a Race bike, we get 6.82 kg (15.04 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
Merida SCULTURA DISC 4000 JULIET it’s weighing 8.41 kg (18.54 lbs). At this weight, is much heavier than average. In conclusion, the average Race bike weighs 23.31% less than SCULTURA DISC 4000 JULIET.
Overview of components
Fork material
The fork is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
As for the wheels, Merida SCULTURA DISC 4000 JULIET 2018, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Merida SCULTURA DISC 4000 JULIET has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
