Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 700c -
Groupset Dura-Ace, Shimano -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SCULTURA DISC CF4
Suspension Fork
Scultura Carbon CF4 Disc 12
Drivetrain
Rear Derailleur
Shimano Dura Ace
Front Derailleur
Shimano Dura Ace
Shift Levers
Shimano RS685 disc
Cassette
Shimano CS-9100-11 11-28
Crank
Rotor 3D30 noQ 52-36 [386]
Bottom Bracket
386EVO, 86mm, press-fit
Chain
KMC X11SL DLC
Wheels
Front Hub
attached / R.A.T. Thru-Axle
Rear Hub
attached / R.A.T. Thru-Axle
Rims
Fulcrum Racing Quattro disc carbon
Spokes
attached
Tires
Continental Grand Prix 4000S 25 KV
Brakes
Brakes
Shimano RS805 160
Brake Levers
Shimano RS685 disc
Cockpit
Handlebar
FSA K-Force Compact OS
Headset
B44-4852-BCP carbon neck pro
Seat
Saddle
Prologo Scratch 2 T2.0
Seatpost
MERIDA EGM-light-27.2 SB15 [E]
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 44cm | 47cm | 50cm | 52cm | 54cm | 56cm | 59cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.34 mm | 1.35 mm | 1.36 mm | 1.39 mm | 1.41 mm | 1.42 mm | 1.44 mm |
| Bottom Bracket Height | 270 mm | 270 mm | 270 mm | 270 mm | 270 mm | 270 mm | 270 mm |
| Front Center | 575 mm | 581 mm | 583 mm | 584 mm | 594 mm | 604 mm | 613 mm |
| Rake | 48 mm | 49 mm | 50 mm | 49 mm | 49 mm | 50 mm | 49 mm |
| Trail | 65 mm | 61 mm | 54 mm | 48 mm | 48 mm | 47 mm | 45 mm |
| Stack | 506 mm | 518 mm | 530 mm | 549 mm | 563 mm | 577 mm | 598 mm |
| Reach | 377 mm | 383 mm | 389 mm | 394 mm | 400 mm | 405 mm | 414 mm |
| Top Tube Length | 516 mm | 526 mm | 541 mm | 551 mm | 566 mm | 581 mm | 596 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 440 mm | 470 mm | 500 mm | 520 mm | 540 mm | 560 mm | 590 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 74 ° |
| Head Tube Length | 105 mm | 115 mm | 125 mm | 140 mm | 155 mm | 170 mm | 190 mm |
| Chainstay Length | 414 mm | 414 mm | 414 mm | 414 mm | 414 mm | 414 mm | 414 mm |
| Wheelbase | 980 mm | 986 mm | 988 mm | 989 mm | 999 mm | 1009 mm | 1018 mm |
| Bottom Bracket Drop | 66 mm | 66 mm | 66 mm | 66 mm | 66 mm | 66 mm | 66 mm |
| Standover Height | 697 mm | 724 mm | 750 mm | 770 mm | 785 mm | 804 mm | 831 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
SCULTURA DISC TEAM belongs to the Merida Scultura model. 214 bikes variations carry this model name so far. You can easily view all of the Merida Scultura bikes models from 2017, here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Race bikes average price
According to our calculations, the average cost of a Race bike that is reliable is 3350$. However, this doesn’t mean that if you spend less money on a Race bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Race bikes average weight
Race bikes have an average weight of 6.82 kg (15.04 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
With a weight of 7.48 kg (16.49 lbs), Merida bike is a bit heavier than average. In other words, this model is 9.68% heavier than the average Race bike.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
As for the wheels, Merida SCULTURA DISC TEAM 2017, has a 700c carbon model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Merida SCULTURA DISC TEAM is equipped with Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
