Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Force eTap -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SCULTURA ENDURANCE CF3 II, material: carbon, 700x35C max./ 700x32C (with fender) max. wheelsize, 100x12/ 142x12mm axle standard, BB86 bottom bracket standard
Suspension Fork
SCULTURA ENDURANCE CF3 disc, material: carbon, 700x35C max. wheelsize
Drivetrain
Rear Derailleur
SRAM Force AXS
Front Derailleur
SRAM Force AXS
Shift Levers
SRAM FORCE AXS
Cassette
SRAM CS XG 1270 D1, 10-36 teeth, 12 speed
Crank
SRAM Force AXS, 46-33 teeth, 170 mm-XXS/XS/S, 172.5 mm-M/L, 175 mm-XL
Bottom Bracket
BB DUB PF ROAD, Pressfit 86.5 mm
Chain
SRAM Force
Wheels
Rims
MERIDA TEAM GR30, 100x12mm width front hub, 142x12mm width rear hub, 25mm inner width, 30mm height, Centerlock, material: carbon
Tires
Continental Terra Speed ProTection, 700x35C, fold
Brakes
Brakes
SRAM Force AXS, Hydraulic disc
Brake Levers
SRAM Force AXS
Cockpit
Handlebar
MERIDA EXPERT GRII, material: aluminium, 380mm(XXS), 400mm (XS-S), 420mm (M-L), 440mm (XL)
Headset
FSA ACR
Seat
Saddle
SCRATCH M5 AGX, V-mount adapter, incl. MERIDA minitool
Seatpost
MERIDA TEAM SL, 27.2mm diameter, 15mm setback, Carbon, S-Flex
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.5 mm | 1.49 mm | 1.53 mm | 1.54 mm | 1.58 mm |
| Bottom Bracket Height | 270 mm | 270 mm | 270 mm | 270 mm | 270 mm | 270 mm |
| Front Center | 583 mm | 588 mm | 592 mm | 592 mm | 608 mm | 617 mm |
| Rake | 49 mm | 48 mm | 48 mm | 48 mm | 49 mm | 47 mm |
| Trail | 68 mm | 66 mm | 60 mm | 53 mm | 52 mm | 51 mm |
| Stack | 545 mm | 558 mm | 571 mm | 590 mm | 609 mm | 635 mm |
| Reach | 366 mm | 372 mm | 382 mm | 386 mm | 395 mm | 403 mm |
| Top Tube Length | 521 mm | 530 mm | 544 mm | 559 mm | 574 mm | 589 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 440 mm | 470 mm | 490 mm | 510 mm | 530 mm | 560 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 72 ° | 73 ° | 73 ° | 73.5 ° |
| Head Tube Length | 140 mm | 152 mm | 161 mm | 177 mm | 197 mm | 222 mm |
| Chainstay Length | 424 mm | 424 mm | 424 mm | 424 mm | 424 mm | 424 mm |
| Wheelbase | 998 mm | 1003 mm | 1007 mm | 1007 mm | 1023 mm | 1032 mm |
| Bottom Bracket Drop | 66 mm | 66 mm | 66 mm | 66 mm | 66 mm | 66 mm |
| Standover Height | 748 mm | 773 mm | 791 mm | 809 mm | 829 mm | 858 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
SCULTURA ENDURANCE GR 8000 belongs to the Merida Scultura model. 214 bikes variations carry this model name so far. Take a sneak peek at all Merida Scultura bikes models from 2024, by clicking here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Endurance bikes
If you want to purchase a solid Endurance bike, it is important to know that the average cost is 2346$. However, even though the average price of an Endurance bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
When leaving the production line, the SCULTURA ENDURANCE GR 8000 model has 700c carbon wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The SCULTURA ENDURANCE GR 8000 has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
