Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset GRX 400, GRX 600 -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SILEX CF2, material: carbon, 700x38C / 650Bx45C max. wheelsize, 100x12/142x12mm axle standard, BB386 bottom bracket standard
Suspension Fork
MERIDA SILEX CF2, Tapered, material: carbon, 700x38C / 650Bx45C max. wheelsize
Drivetrain
Rear Derailleur
Shimano GRX400
Front Derailleur
Shimano GRX400
Shift Levers
Shimano GRX400
Cassette
Shimano CS-HG50, 11-36 teeth, 10 speed
Crank
Shimano GRX600, 46-30 teeth, 170 mm-XS/S, 172,5 mm-M, 175 mm-L/XL
Bottom Bracket
FSA 386-BB30 PF6000 [SRAM FC]
Chain
KMC X10
Wheels
Front Hub
VP CLK170F / VP CLK270R, 100x12mm width front hub, 32 spoke holes, centerlock, 142x12mm width rear hub, 32 spoke holes, centerlock
Rear Hub
VP CLK170F / VP CLK270R, 100x12mm width front hub, 32 spoke holes, centerlock, 142x12mm width rear hub, 32 spoke holes, centerlock
Rims
MERIDA COMP SL, 17mm inner width, 22mm height, material: aluminium
Spokes
Black stainless
Tires
Front: Maxxis Rambler, 700x38C, fold, TR, EXO, Rear: Maxxis Rambler, 700x38C, fold, TR, EXO
Brakes
Brakes
Shimano GRX400, Hydraulic disc
Brake Levers
Shimano GRX400
Cockpit
Stem
MERIDA EXPERT CW, material: aluminium, 31.8mm diameter, -8° stem angle, 80 mm all sizes
Handlebar
MERIDA EXPERT GR, material: aluminium, 400mm (XS-S), 420mm (M), 440mm (L/XL)
Headset
SILEX Neck
Seat
Saddle
MERIDA COMP SL, V-mount
Seatpost
MERIDA EXPERT CC, material: carbon, 30.9mm diameter, 0mm setback
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.55 mm | 1.56 mm | 1.55 mm | 1.54 mm |
| Bottom Bracket Height | 274 mm | 274 mm | 274 mm | 274 mm |
| Front Center | 625 mm | 642 mm | 663 mm | 685 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 73 mm | 73 mm | 73 mm | 73 mm |
| Stack | 609 mm | 628 mm | 647 mm | 666 mm |
| Reach | 392 mm | 402 mm | 417 mm | 432 mm |
| Top Tube Length | 566 mm | 582 mm | 602 mm | 622 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 470 mm | 500 mm | 530 mm | 560 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 180 mm | 200 mm | 220 mm | 240 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1046 mm | 1063 mm | 1084 mm | 1106 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm | 75 mm |
| Standover Height | 738 mm | 767 mm | 796 mm | 824 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
SILEX 4000 belongs to the Merida Silex model. There are 43 bikes that carry this model name. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Merida SILEX 300 2023 is the most economical model, with a starting price of 1273$. Merida SILEX 4000 2023 on the other hand costs 2615$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Gravel bikes average price
If you want an acceptable Gravel bike you should know that the average price is 2462$. However, even though the average price of a Gravel bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2023 for 2615$. Comparing the average cost of a Gravel bike to this one, you will see that SILEX 4000 price is 6.21% higher.
SILEX 4000 components
Fork material
SILEX 4000 has a carbon fork, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
As for the wheels, Merida SILEX 4000 2023, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Merida SILEX 4000 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
SILEX 4000 comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
