Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 700c -
Groupset Claris, Altus -
Suspension Rigid -
Drivetrain 3 × 8 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SPEEDER LITE
Suspension Fork
Speeder BC Alloy straight disc
Drivetrain
Rear Derailleur
Shimano Claris GS
Front Derailleur
Shimano M191 48
Shift Levers
Shimano EZ fire
Cassette
Sunrace CS-8S 11-28
Crank
Shimano M131 48-38-28 CG (BSA)
Bottom Bracket
BSA, threaded
Chain
8s
Wheels
Front Hub
Alloy Disc / Alloy Disc cassette
Rear Hub
Alloy Disc / Alloy Disc cassette
Rims
MERIDA comp 22 disc
Spokes
Black stainless
Tires
Kenda K193 700 32
Brakes
Brakes
Promax MTD Mechanical 160
Cockpit
Handlebar
MERIDA comp OS 600 Flat
Headset
FSA No.57/No.61BP
Seat
Saddle
MERIDA Sport 5
Seatpost
MERIDA road comp SB12 31.6
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 50cm | 52cm | 54cm | 56cm | 59cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.54 mm | 1.56 mm | 1.58 mm | 1.64 mm | 1.71 mm | 1.73 mm |
| Front Center | 591 mm | 582 mm | 591 mm | 591 mm | 590 mm | 605 mm |
| Rake | 45 mm | 39 mm | 44 mm | 44 mm | 40 mm | 39 mm |
| Trail | 73 mm | 72 mm | 67 mm | 64 mm | 65 mm | 66 mm |
| Stack | 568 mm | 581 mm | 591 mm | 611 mm | 637 mm | 661 mm |
| Reach | 370 mm | 372 mm | 373 mm | 372 mm | 373 mm | 381 mm |
| Top Tube Length | 527 mm | 532 mm | 542 mm | 552 mm | 567 mm | 582 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 470 mm | 500 mm | 520 mm | 540 mm | 560 mm | 590 mm |
| Head Tube Angle | 71 ° | 72 ° | 72 ° | 72.5 ° | 73 ° | 73 ° |
| Head Tube Length | 150 mm | 160 mm | 170 mm | 190 mm | 215 mm | 240 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1020 mm | 1010 mm | 1020 mm | 1020 mm | 1019 mm | 1034 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 747 mm | 772 mm | 789 mm | 807 mm | 828 mm | 856 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
SPEEDER 100 belongs to the Merida Speeder model. 90 bikes variations carry this model name so far. Check out the entire range from 2016 of this model, by clicking this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Fitness bikes average price
According to our calculations, the average cost of a Fitness bike that is reliable is 656$. However, even though the average price of a Fitness bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Fitness bikes average weight
Fitness bikes weigh an average of 11.24 kg (24.78 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
SPEEDER 100 weighs 11.2 kg (24.69 lbs) and is slightly lighter than the average. To sum up, it’s 0.36% lighter than the average weight of Fitness bikes.
SPEEDER 100 components
Fork material
SPEEDER 100 has an aluminum fork, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels
When it comes to wheels, the SPEEDER 100 bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Merida SPEEDER 100 is equipped with Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
