Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 700c -
Groupset Acera, Tourney -
Suspension Rigid -
Drivetrain 3 × 8 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SPEEDER LITE
Suspension Fork
Full carbon tapered fork with disc mounts
Drivetrain
Rear Derailleur
Shimano Acera-X
Front Derailleur
Shimano TY710 48
Shift Levers
Shimano EF505, 24 speed, EZ-fire
Cassette
Sunrace CSM668, 8 speed, 11-32 teeth
Crank
Shimano TY301 48-38-28 with chainguard
Chain
8 Speed
Wheels
Front Hub
Shimano, quick release, centerlock
Rear Hub
Shimano, quick release, centerlock
Rims
MERIDA Comp, 22mm profile
Spokes
Black stainless
Tires
Maxxis Detonator 32c 60tpi
Brakes
Brakes
Shimano EF505 hydraulic disc brakes with 160mm centerlock rotors
Brake Levers
attached
Cockpit
Handlebar
MERIDA Expert Oversize clamp 600mm wide Flat
Headset
MERIDA M2341
Seat
Saddle
MERIDA Sport
Seatpost
MERIDA Road Comp 12mm, 31.6mm offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | SM/MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.54 mm | 1.56 mm | 1.58 mm | 1.64 mm | 1.71 mm | 1.73 mm |
| Front Center | 591 mm | 583 mm | 592 mm | 591 mm | 590 mm | 605 mm |
| Rake | 45 mm | 40 mm | 45 mm | 44 mm | 40 mm | 39 mm |
| Trail | 73 mm | 71 mm | 66 mm | 64 mm | 65 mm | 66 mm |
| Stack | 568 mm | 581 mm | 591 mm | 611 mm | 637 mm | 661 mm |
| Reach | 370 mm | 372 mm | 373 mm | 372 mm | 373 mm | 381 mm |
| Top Tube Length | 527 mm | 532 mm | 542 mm | 552 mm | 567 mm | 582 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 470 mm | 500 mm | 520 mm | 540 mm | 560 mm | 590 mm |
| Head Tube Angle | 71 ° | 72 ° | 72 ° | 72.5 ° | 73 ° | 73 ° |
| Head Tube Length | 150 mm | 160 mm | 170 mm | 190 mm | 215 mm | 240 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1020 mm | 1011 mm | 1021 mm | 1020 mm | 1019 mm | 1034 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 747 mm | 773 mm | 789 mm | 808 mm | 828 mm | 856 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
SPEEDER 100 belongs to the Merida Speeder model. Merida released 90 bikes variations of this model so far. Take a sneak peek at all Merida Speeder bikes models from 2018, by clicking here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Fitness bikes average price
If you want an acceptable Fitness bike you should know that the average price is 656$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Fitness bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Average weight for Fitness bikes
The average weight for Fitness bikes is 11.24 kg (24.78 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
SPEEDER 100 weighs 10.44 kg (23.02 lbs) and is a bit lighter than the average. In other words, this model is 7.66% lighter than the average Fitness bike.
Overview of components
Fork material
SPEEDER 100 has a carbon fork, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
When leaving the production line, the SPEEDER 100 model has 700c aluminum wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The SPEEDER 100 has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
