Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Acera, Tourney -
Suspension Rigid -
Drivetrain 3 × 8 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SPEEDER LITE II, material: aluminium, 700x35C max. wheelsize, 100x9/135x9mm axle standard, BSA bottom bracket standard
Suspension Fork
MERIDA SPEEDER CF2, Tapered, material: carbon, 700x35C max. wheelsize
Drivetrain
Rear Derailleur
Shimano Acera-X
Front Derailleur
Shimano TY710
Shift Levers
Shimano ST-EF505
Cassette
Sunrace CSM558, 11-32 teeth, 8 speed
Crank
Shimano TY301, 48-38-28 teeth, 170 mm-all sizes
Bottom Bracket
FSA TH-7420ST Cartridge Bearing
Chain
Sunrace CN-M84
Pedals
VP VPE-891
Wheels
Front Hub
Joytech D471SBT-SC-CL / Shimano FH-TX505, 100x9mm width front hub, 28 spoke holes, centerlock, 135x9mm width rear hub, 32 spoke holes, centerlock
Rear Hub
Joytech D471SBT-SC-CL / Shimano FH-TX505, 100x9mm width front hub, 28 spoke holes, centerlock, 135x9mm width rear hub, 32 spoke holes, centerlock
Rims
MERIDA COMP SL, 17mm inner width, 22mm height, material: aluminium
Spokes
Black stainless
Tires
Front: Maxxis Detonator, 700x32C, wire, Rear: Maxxis Detonator, 700x32C, wire
Brakes
Brakes
Shimano ST-EF505, BR-MT200 brake caliper
Brake Levers
Shimano EF505
Cockpit
Stem
MERIDA COMP CC, material: aluminium, 31.8mm diameter, 6° stem angle, 80 mm-XS, 90 mm-S, 100 mm-SM/ML, 110 mm-L/XL
Handlebar
MERIDA COMP TK, material: aluminium, 600mm width, Flat
Headset
MERIDA M2341 Neck
Seat
Saddle
MERIDA COMP SL, V-mount
Seatpost
MERIDA COMP CC, material: aluminium, 30.9mm diameter, 12mm setback
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | SM/MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.46 mm | 1.47 mm | 1.5 mm | 1.54 mm | 1.57 mm |
| Front Center | 621 mm | 623 mm | 627 mm | 635 mm | 644 mm | 658 mm |
| Rake | 45 mm | 45 mm | 44 mm | 44 mm | 45 mm | 45 mm |
| Trail | 79 mm | 76 mm | 74 mm | 70 mm | 66 mm | 66 mm |
| Stack | 564 mm | 575 mm | 587 mm | 608 mm | 633 mm | 657 mm |
| Reach | 391 mm | 394 mm | 400 mm | 406 mm | 412 mm | 418 mm |
| Top Tube Length | 557 mm | 563 mm | 573 mm | 585 mm | 599 mm | 612 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 470 mm | 500 mm | 520 mm | 540 mm | 560 mm | 590 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71.5 ° | 72 ° | 72 ° |
| Head Tube Length | 150 mm | 160 mm | 170 mm | 190 mm | 215 mm | 240 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1053 mm | 1055 mm | 1059 mm | 1067 mm | 1076 mm | 1090 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 746 mm | 771 mm | 789 mm | 808 mm | 830 mm | 857 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
SPEEDER 100 is part of the Merida Speeder model. 90 bikes variations carry this model name so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Merida SPEEDER 10-V (L) 2023 is the cheapest bike model and costs 394$. Merida SPEEDER 900 2023 is the most expensive one and costs 1825$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Fitness bikes
According to our math, the average price for a trustworthy Fitness bike is 656$. However, this doesn’t mean that if you spend less money on a Fitness bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
When Merida released this model in 2023, its price was 912$. Doing a quick comparison, we notice that SPEEDER 100 price is 39.02% more expensive than the average cost of a Fitness bike.
SPEEDER 100 components
Fork material
The fork on this bike is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
When it comes to wheels, the SPEEDER 100 bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Merida SPEEDER 100 has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
