Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 700c -
Groupset Sora, FSA -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SPEEDER LITE
Suspension Fork
MERIDA SPEEDER CF2
Drivetrain
Rear Derailleur
Shimano Sora, SS
Front Derailleur
Shimano Sora
Shift Levers
Shimano SL-R3000 / Shimano SL-R3000 9
Cassette
Shimano CS-HG200, 11-32 teeth, 9 speed
Crank
FSA Tempo, 50-34 teeth
Chain
KMC M99
Wheels
Front Hub
Shimano HB-TX505, 100x9mm width, 32 spoke holes, centerlock / Shimano FH-TX505, 135x9mm width, 32 spoke holes, centerlock
Rear Hub
Shimano HB-TX505, 100x9mm width, 32 spoke holes, centerlock / Shimano FH-TX505, 135x9mm width, 32 spoke holes, centerlock
Rims
MERIDA Comp SL, 17mm inner width, 22mm height
Spokes
Black stainless
Tires
Maxxis Detonator, 700x32C, wire
Brakes
Brakes
Shimano BR-MT200 JKIT / Shimano BR-MT200
Brake Levers
Shimano MT-200
Cockpit
Handlebar
MERIDA Comp TK, 600mm width, Flat
Headset
MERIDA 2341 Neck, 2191022388
Seat
Saddle
MERIDA Comp SL
Seatpost
MERIDA Comp CC, 31.6mm diameter, 15mm setback
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | SM/MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.54 mm | 1.56 mm | 1.58 mm | 1.64 mm | 1.71 mm | 1.73 mm |
| Front Center | 591 mm | 583 mm | 592 mm | 591 mm | 590 mm | 605 mm |
| Rake | 45 mm | 40 mm | 45 mm | 44 mm | 40 mm | 39 mm |
| Trail | 73 mm | 71 mm | 66 mm | 64 mm | 65 mm | 66 mm |
| Stack | 568 mm | 581 mm | 591 mm | 611 mm | 637 mm | 661 mm |
| Reach | 370 mm | 372 mm | 373 mm | 372 mm | 373 mm | 381 mm |
| Top Tube Length | 527 mm | 532 mm | 542 mm | 552 mm | 567 mm | 582 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 470 mm | 500 mm | 520 mm | 540 mm | 560 mm | 590 mm |
| Head Tube Angle | 71 ° | 72 ° | 72 ° | 72.5 ° | 73 ° | 73 ° |
| Head Tube Length | 150 mm | 160 mm | 170 mm | 190 mm | 215 mm | 240 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1020 mm | 1011 mm | 1021 mm | 1020 mm | 1019 mm | 1034 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 747 mm | 773 mm | 789 mm | 808 mm | 828 mm | 856 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
SPEEDER 200 completes the Merida Speeder model. Merida launched 90 bikes of this model so far. You can get a glimpse at all models from 2019, by clicking on this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Fitness bikes average price
If you want an acceptable Fitness bike you should know that the average price is 656$. However, this doesn’t mean that if you spend less money on a Fitness bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Fitness bikes average weight
The average weight for Fitness bikes is 11.24 kg (24.78 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
With a weight of 10.18 kg (22.44 lbs), Merida bike is considerably lighter than average. In conclusion, the average Fitness bike weighs 10.41% more than SPEEDER 200.
SPEEDER 200 components
Wheels size
When it comes to wheels, the SPEEDER 200 bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
