Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 700c -
Groupset Tiagra, Shimano -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SPEEDER LITE
Suspension Fork
Speeder BC Alloy straight disc
Drivetrain
Rear Derailleur
Shimano TIAGRA SS
Front Derailleur
Shimano TIAGRA D
Shift Levers
Shimano SL-4700 / Shimano SL-4700 10
Cassette
Shimano CS-HG500-10 12-28
Crank
FSA Omega 50-34 Mega (BSA)
Bottom Bracket
BSA, threaded
Chain
KMC X10
Wheels
Front Hub
Bearing Disc / Bearing Disc Cassette
Rear Hub
Bearing Disc / Bearing Disc Cassette
Rims
MERIDA comp 22 disc
Spokes
Black stainless
Tires
Maxxis Detonator 32 60
Brakes
Brakes
Tektro Vela hydraulic 160
Cockpit
Handlebar
MERIDA pro OS 600 Flat
Headset
FSA No.57/No.61BP
Seat
Saddle
MERIDA Sport 5
Seatpost
MERIDA pro H SB15 31.6
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 50cm | 52cm | 54cm | 56cm | 59cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.54 mm | 1.56 mm | 1.58 mm | 1.64 mm | 1.71 mm | 1.73 mm |
| Front Center | 591 mm | 582 mm | 591 mm | 591 mm | 590 mm | 605 mm |
| Rake | 45 mm | 39 mm | 44 mm | 44 mm | 40 mm | 39 mm |
| Trail | 73 mm | 72 mm | 67 mm | 64 mm | 65 mm | 66 mm |
| Stack | 568 mm | 581 mm | 591 mm | 611 mm | 637 mm | 661 mm |
| Reach | 370 mm | 372 mm | 373 mm | 372 mm | 373 mm | 381 mm |
| Top Tube Length | 527 mm | 532 mm | 542 mm | 552 mm | 567 mm | 582 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 470 mm | 500 mm | 520 mm | 540 mm | 560 mm | 590 mm |
| Head Tube Angle | 71 ° | 72 ° | 72 ° | 72.5 ° | 73 ° | 73 ° |
| Head Tube Length | 150 mm | 160 mm | 170 mm | 190 mm | 215 mm | 240 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1020 mm | 1010 mm | 1020 mm | 1020 mm | 1019 mm | 1034 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 747 mm | 772 mm | 789 mm | 807 mm | 828 mm | 856 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
SPEEDER 300 completes the Merida Speeder model. There are 90 bikes that carry this model name. Take a sneak peek at all Merida Speeder bikes models from 2016, by clicking here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Fitness bikes
According to our math, the average price for a trustworthy Fitness bike is 656$. However, you could also get a good Fitness bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Fitness bikes average weight
The average weight for Fitness bikes is 11.24 kg (24.78 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
SPEEDER 300 weighs 10.6 kg (23.37 lbs) and is a bit lighter than the average. In other words, this model is 6.04% lighter than the average Fitness bike.
SPEEDER 300 components
Fork material
The fork on this bike is made out of aluminum, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Wheels
When it comes to wheels, the SPEEDER 300 bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Merida SPEEDER 300 has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
