Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 700c -
Groupset Apex 1 -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SPEEDER LITE
Suspension Fork
MERIDA SPEEDER CF2
Drivetrain
Rear Derailleur
SRAM Apex1
Shift Levers
no / SRAM Apex Trigger
Cassette
SRAM PG-1130, 11-42 teeth, 11 speed
Crank
SRAM Apex1, 44 teeth
Chain
KMC X11
Wheels
Front Hub
Joytech MICC-1503, 100x9mm width, 28 spoke holes, centerlock / Joytech MICC-1504, 135x9mm width, 28 spoke holes, centerlock
Rear Hub
Joytech MICC-1503, 100x9mm width, 28 spoke holes, centerlock / Joytech MICC-1504, 135x9mm width, 28 spoke holes, centerlock
Rims
MERIDA Comp SL, 17mm inner width, 22mm height
Spokes
Black stainless
Tires
Maxxis Detonator, 700x32C, wire
Brakes
Brakes
Shimano BR-MT200 JKIT / Shimano BR-MT200
Brake Levers
Shimano MT-200
Cockpit
Handlebar
MERIDA Expert CC, 600mm width, Flat
Headset
MERIDA 2341 Neck, 2191022388
Seat
Saddle
MERIDA Comp SL
Seatpost
MERIDA Comp CC, 31.6mm diameter, 15mm setback
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | SM/MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.54 mm | 1.56 mm | 1.58 mm | 1.64 mm | 1.71 mm | 1.73 mm |
| Front Center | 591 mm | 583 mm | 592 mm | 591 mm | 590 mm | 605 mm |
| Rake | 45 mm | 40 mm | 45 mm | 44 mm | 40 mm | 39 mm |
| Trail | 73 mm | 71 mm | 66 mm | 64 mm | 65 mm | 66 mm |
| Stack | 568 mm | 581 mm | 591 mm | 611 mm | 637 mm | 661 mm |
| Reach | 370 mm | 372 mm | 373 mm | 372 mm | 373 mm | 381 mm |
| Top Tube Length | 527 mm | 532 mm | 542 mm | 552 mm | 567 mm | 582 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 470 mm | 500 mm | 520 mm | 540 mm | 560 mm | 590 mm |
| Head Tube Angle | 71 ° | 72 ° | 72 ° | 72.5 ° | 73 ° | 73 ° |
| Head Tube Length | 150 mm | 160 mm | 170 mm | 190 mm | 215 mm | 240 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1020 mm | 1011 mm | 1021 mm | 1020 mm | 1019 mm | 1034 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 747 mm | 773 mm | 789 mm | 808 mm | 828 mm | 856 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
SPEEDER 300 completes the Merida Speeder model. 90 bikes variations carry this model name so far. You can get a glimpse at all models from 2019, by clicking on this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Fitness bikes
According to our calculations, the average cost of a Fitness bike that is reliable is 656$. However, you could also get a good Fitness bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Average weight for Fitness bikes
The average weight for Fitness bikes is 11.24 kg (24.78 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
With a weight of 9.55 kg (21.05 lbs), Merida bike is much lighter than average. In short, the average Fitness bike weight is 17.7% higher than this one.
SPEEDER 300 components
Wheels
As for the wheels, Merida SPEEDER 300 2019, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The SPEEDER 300 has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
