Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 700c -
Groupset Tiagra, Shimano -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SPEEDER LITE II, material: aluminium, 700x35C max. wheelsize, 100x9/135x9mm axle standard, BSA bottom bracket standard, MUK 8 Hanger
Suspension Fork
MERIDA SPEEDER CF2, Tapered, material: carbon, 700x35C max. wheelsize
Drivetrain
Rear Derailleur
Shimano Tiagra, GS
Front Derailleur
Shimano Tiagra
Shift Levers
Shimano Tiagra
Cassette
Shimano CS-HG500, 11-32 teeth, 10 speed
Crank
Shimano FC-RS400, 50-34 teeth, 170 mm-XS/S/SM/ML, 175 mm-L/XL
Bottom Bracket
Shimano BB-RS500 BSA
Chain
KMC X10
Wheels
Front Hub
Joytech D471SBT-SC-CL / Joytech D472TSBT-SC-CL, 100x9mm width front hub, 28 spoke holes, centerlock, 135x9mm width rear hub, 28 spoke holes, centerlock
Rear Hub
Joytech D471SBT-SC-CL / Joytech D472TSBT-SC-CL, 100x9mm width front hub, 28 spoke holes, centerlock, 135x9mm width rear hub, 28 spoke holes, centerlock
Rims
MERIDA COMP SL, 17mm inner width, 22mm height, material: aluminium
Spokes
Black stainless
Tires
Maxxis Detonator, 700x32C, wire
Brakes
Brakes
Tektro M275, 2 piston
Brake Levers
Tektro M275
Disk Rotors
Shimano RT10, 160 mm
Cockpit
Stem
MERIDA EXPERT CC, material: aluminium, 31.8mm diameter, 5° stem angle, 80 mm-XS, 90 mm-S, 100 mm-SM/ML, 110 mm-L/XL
Handlebar
MERIDA EXPERT CC, material: aluminium, 600mm width, Flat
Headset
MERIDA M2341 Neck
Seat
Saddle
MERIDA COMP SL, V-mount
Seatpost
MERIDA COMP CC, material: aluminium, 30.9mm diameter, 12mm setback
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | SM/MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.46 mm | 1.47 mm | 1.5 mm | 1.54 mm | 1.57 mm |
| Front Center | 621 mm | 623 mm | 627 mm | 635 mm | 644 mm | 658 mm |
| Rake | 45 mm | 45 mm | 44 mm | 44 mm | 45 mm | 45 mm |
| Trail | 79 mm | 76 mm | 74 mm | 70 mm | 66 mm | 66 mm |
| Stack | 564 mm | 575 mm | 587 mm | 608 mm | 633 mm | 657 mm |
| Reach | 391 mm | 394 mm | 400 mm | 406 mm | 412 mm | 418 mm |
| Top Tube Length | 557 mm | 563 mm | 573 mm | 585 mm | 599 mm | 612 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 470 mm | 500 mm | 520 mm | 540 mm | 560 mm | 590 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71.5 ° | 72 ° | 72 ° |
| Head Tube Length | 150 mm | 160 mm | 170 mm | 190 mm | 215 mm | 240 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1053 mm | 1055 mm | 1059 mm | 1067 mm | 1076 mm | 1090 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 746 mm | 771 mm | 789 mm | 808 mm | 830 mm | 857 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
SPEEDER 300 completes the Merida Speeder model. Merida released 90 bikes variations of this model so far. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
Merida SPEEDER 10-V (L) 2022 is the cheapest bike model and costs 394$. Merida SPEEDER 900 2022 is the most expensive one and costs 1825$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Fitness bikes average price
According to our calculations, the average cost of a Fitness bike that is reliable is 656$. However, you could also get a good Fitness bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When Merida released this model in 2022, its price was 1216$. If we compare this with the average Fitness bike cost we notice that the price is 85.37% more expensive.
SPEEDER 300 components
Fork material
The fork is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
As for the wheels, Merida SPEEDER 300 2022, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Merida SPEEDER 300 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
