Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 700c -
Groupset 105, Tiagra -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SPEEDER DISC CF2
Suspension Fork
Race carbon disc 15
Drivetrain
Rear Derailleur
Shimano 105 SS
Front Derailleur
Shimano TIAGRA 10 D
Shift Levers
Shimano SL-R460 / Shimano SL-R460 10
Cassette
Shimano CS-4600-10 12-28
Crank
FSA Omega 50-34 Mega
Bottom Bracket
attached
Chain
KMC Z10-10s
Wheels
Front Hub
Formula Centerlock-15 Road Axle / Formula Centerlock casette
Rear Hub
Formula Centerlock-15 Road Axle / Formula Centerlock casette
Rims
MERIDA comp 22 disc pair
Tires
Maxxis Detonator 28 60 fold
Brakes
Brakes
Shimano M506 160 cen J
Brake Levers
attached
Cockpit
Handlebar
MERIDA pro OS 600 Flat
Headset
Big Conoid S-bearing neck pro
Seat
Saddle
MERIDA Sport 1
Seatpost
MERIDA carbon H SB15 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 50cm | 52cm | 54cm | 56cm | 59cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.53 mm | 1.54 mm | 1.55 mm | 1.59 mm | 1.59 mm | 1.62 mm |
| Front Center | 569 mm | 572 mm | 579 mm | 586 mm | 602 mm | 617 mm |
| Rake | 47 mm | 47 mm | 47 mm | 44 mm | 46 mm | 47 mm |
| Trail | 70 mm | 64 mm | 61 mm | 61 mm | 59 mm | 58 mm |
| Stack | 543 mm | 558 mm | 572 mm | 598 mm | 612 mm | 636 mm |
| Reach | 355 mm | 362 mm | 370 mm | 377 mm | 386 mm | 393 mm |
| Top Tube Length | 520 mm | 532 mm | 544 mm | 556 mm | 572 mm | 587 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 470 mm | 500 mm | 520 mm | 540 mm | 560 mm | 590 mm |
| Head Tube Angle | 71 ° | 72 ° | 72.5 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 140 mm | 152 mm | 165 mm | 180 mm | 205 mm | 230 mm |
| Chainstay Length | 414 mm | 414 mm | 414 mm | 414 mm | 414 mm | 414 mm |
| Wheelbase | 973 mm | 976 mm | 983 mm | 990 mm | 1006 mm | 1021 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm |
| Standover Height | 786 mm | 811 mm | 830 mm | 849 mm | 870 mm | 899 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Speeder 3000 is part of the Merida Speeder model. 90 bikes variations carry this model name so far. Check out the entire range from 2015 of this model, by clicking this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Fitness bikes
Our math shows that the average cost of a dependable Fitness bike is 656$. However, even if your budget is less than the average, you might still be able to get a top-quality Fitness bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Speeder 3000 components
Fork material
When it comes to the fork, this bike has a carbon one, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
When it comes to wheels, the Speeder 3000 bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Speeder 3000 comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
