Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 700c -
Groupset 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SPEEDER LITE
Suspension Fork
Speeder BC Alloy straight disc
Drivetrain
Rear Derailleur
Shimano 105 SS
Front Derailleur
Shimano 105 D
Shift Levers
Shimano SL-RS700 / Shimano SL-RS700 11
Cassette
Shimano CS-5800-11 11-28
Crank
Shimano 105 50-34 [BSA]
Bottom Bracket
BSA, threaded
Chain
KMC X11
Wheels
Front Hub
Bearing Centerlock
Rear Hub
Bearing Centerlock
Rims
MERIDA comp 22 disc pair
Spokes
Black stainless
Tires
Maxxis Detonator 28 60 fold
Brakes
Brakes
Shimano M315 160 cen
Brake Levers
Shimano M315
Cockpit
Handlebar
MERIDA Expert OS 600 Flat
Headset
Big Conoid S-bearing neck pro
Seat
Saddle
Juliet Sport
Seatpost
MERIDA Expert SB15 31.6
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 50cm | 52cm | 54cm |
|---|---|---|---|---|
| Stack Reach Ratio | 1.54 mm | 1.56 mm | 1.58 mm | 1.64 mm |
| Front Center | 591 mm | 583 mm | 592 mm | 591 mm |
| Rake | 45 mm | 40 mm | 45 mm | 44 mm |
| Trail | 73 mm | 71 mm | 66 mm | 64 mm |
| Stack | 568 mm | 581 mm | 591 mm | 611 mm |
| Reach | 370 mm | 372 mm | 373 mm | 372 mm |
| Top Tube Length | 527 mm | 532 mm | 542 mm | 552 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74 ° | 73.5 ° |
| Seat Tube Length | 470 mm | 500 mm | 520 mm | 540 mm |
| Head Tube Angle | 71 ° | 72 ° | 72 ° | 72.5 ° |
| Head Tube Length | 150 mm | 160 mm | 170 mm | 190 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1020 mm | 1011 mm | 1021 mm | 1020 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 747 mm | 773 mm | 789 mm | 808 mm |
| Wheels | 700 | 700 | 700 | 700 |
Model Overview
SPEEDER 400 JULIET is part of the Merida Speeder model. Merida launched 90 bikes of this model so far. You can easily view all of the Merida Speeder bikes models from 2017, here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Fitness bikes
If you want an acceptable Fitness bike you should know that the average price is 656$. However, even if your budget is less than the average, you might still be able to get a top-quality Fitness bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Average weight for Fitness bikes
If we make a quick analysis of the average weight of a Fitness bike, we get 11.24 kg (24.78 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
SPEEDER 400 JULIET weighs 10.06 kg (22.18 lbs) and is considerably lighter than the average. In other words, this model is 11.73% lighter than the average Fitness bike.
SPEEDER 400 JULIET components
Fork material
The fork on this bike is made out of aluminum, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Wheels
The wheels on SPEEDER 400 JULIET are the 700c aluminum type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
