Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 700c -
Groupset Ultegra, 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SPEEDER LITE
Suspension Fork
MERIDA SPEEDER CF2
Drivetrain
Rear Derailleur
Shimano Ultegra, GS
Front Derailleur
Shimano Ultegra
Shift Levers
Shimano SL-RS700
Cassette
Shimano CS-R7000, 11-32 teeth, 11 speed
Crank
FSA Gossamer, 50-34 teeth
Chain
KMC X11
Wheels
Front Hub
Joytech MICC-1503, 100x9mm width, 28 spoke holes, centerlock / Joytech MICC-1504, 135x9mm width, 28 spoke holes, centerlock
Rear Hub
Joytech MICC-1503, 100x9mm width, 28 spoke holes, centerlock / Joytech MICC-1504, 135x9mm width, 28 spoke holes, centerlock
Rims
MERIDA Comp SL, 17mm inner width, 22mm height
Spokes
Black stainless
Tires
Maxxis Detonator, 700x28C, fold
Brakes
Brakes
Shimano MT-500
Brake Levers
Shimano MT-501
Cockpit
Handlebar
MERIDA Expert CC, 600mm width, Flat
Headset
MERIDA M2331 Neck, 2191025659
Seat
Saddle
MERIDA Comp SL
Seatpost
MERIDA Expert CC, 31.6mm diameter, 15mm setback, Carbon
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | SM/MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.54 mm | 1.56 mm | 1.58 mm | 1.64 mm | 1.71 mm | 1.73 mm |
| Front Center | 591 mm | 583 mm | 592 mm | 591 mm | 590 mm | 605 mm |
| Rake | 45 mm | 40 mm | 45 mm | 44 mm | 40 mm | 39 mm |
| Trail | 73 mm | 71 mm | 66 mm | 64 mm | 65 mm | 66 mm |
| Stack | 568 mm | 581 mm | 591 mm | 611 mm | 637 mm | 661 mm |
| Reach | 370 mm | 372 mm | 373 mm | 372 mm | 373 mm | 381 mm |
| Top Tube Length | 527 mm | 532 mm | 542 mm | 552 mm | 567 mm | 582 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 470 mm | 500 mm | 520 mm | 540 mm | 560 mm | 590 mm |
| Head Tube Angle | 71 ° | 72 ° | 72 ° | 72.5 ° | 73 ° | 73 ° |
| Head Tube Length | 150 mm | 160 mm | 170 mm | 190 mm | 215 mm | 240 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1020 mm | 1011 mm | 1021 mm | 1020 mm | 1019 mm | 1034 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 747 mm | 773 mm | 789 mm | 808 mm | 828 mm | 856 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
SPEEDER 500 completes the Merida Speeder model. Merida launched 90 bikes of this model so far. Check out the entire range from 2019 of this model, by clicking this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Fitness bikes average price
Our math shows that the average cost of a dependable Fitness bike is 656$. However, you could also get a good Fitness bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Fitness bikes average weight
On a deeper look, we notice that the average weight of a Fitness bike is 11.24 kg (24.78 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
much lighter than average, SPEEDER 500 has a weight of 8.86 kg (19.53 lbs). To sum up, it’s 26.86% lighter than the average weight of Fitness bikes.
Overview of components
Wheels size
When leaving the production line, the SPEEDER 500 model has 700c aluminum wheels. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Merida SPEEDER 500 has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
