Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 700c -
Groupset Ultegra, 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SPEEDER DISC CF3
Suspension Fork
Race carbon disc 15
Drivetrain
Rear Derailleur
Shimano Ultegra SS
Front Derailleur
Shimano Ultegra D
Shift Levers
Shimano SL-RS700 / Shimano SL-RS700 11
Cassette
Shimano CS-5800-11 11-28
Crank
FSA Gossamer 50-34 Mega (BB86)
Bottom Bracket
BB86/BB92, press-fit
Chain
KMC X11
Wheels
Front Hub
Formula Centerlock-15 Road Axle / Formula Centerlock-12 11s
Rear Hub
Formula Centerlock-15 Road Axle / Formula Centerlock-12 11s
Rims
MERIDA comp 22 disc pair
Spokes
Black stainless
Tires
Maxxis Detonator 28 60 fold
Brakes
Brakes
Shimano M615 160 cen J
Cockpit
Handlebar
MERIDA pro OS 600 Flat
Headset
FSA BB410P/No.55E
Seat
Saddle
Prologo Kappa 3
Seatpost
MERIDA carbon H SB15 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 50cm | 53cm | 56cm | 59cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.44 mm | 1.46 mm | 1.48 mm | 1.5 mm |
| Front Center | 579 mm | 575 mm | 589 mm | 598 mm | 614 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 72 mm | 65 mm | 65 mm | 62 mm | 62 mm |
| Stack | 523 mm | 537 mm | 556 mm | 576 mm | 596 mm |
| Reach | 372 mm | 372 mm | 381 mm | 389 mm | 398 mm |
| Top Tube Length | 522 mm | 532 mm | 547 mm | 560 mm | 575 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 470 mm | 500 mm | 530 mm | 560 mm | 590 mm |
| Head Tube Angle | 71 ° | 72 ° | 72 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 100 mm | 111 mm | 131 mm | 150 mm | 171 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 994 mm | 990 mm | 1005 mm | 1014 mm | 1030 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Standover Height | 792 mm | 817 mm | 844 mm | 872 mm | 897 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
SPEEDER 5000 is part of the Merida Speeder model. Merida released 90 bikes variations of this model so far. You can get a glimpse at all models from 2016, by clicking on this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Fitness bikes average price
Our math shows that the average cost of a dependable Fitness bike is 656$. However, this doesn’t mean that if you spend less money on a Fitness bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Fitness bikes average weight
The average weight for Fitness bikes is 11.24 kg (24.78 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
With a weight of 8.4 kg (18.52 lbs), Merida bike is much lighter than average. To sum up, it’s 33.81% lighter than the average weight of Fitness bikes.
SPEEDER 5000 components
Fork material
SPEEDER 5000 has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
As for the wheels, Merida SPEEDER 5000 2016, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Merida SPEEDER 5000 has Mechanical Disc brakes installed. They deliver good performance and cost less than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
