Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 700c -
Groupset 105, Sora -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Speeder Ride-V-Single
Suspension Fork
Speeder Lite
Drivetrain
Rear Derailleur
Shimano 105 SS
Front Derailleur
Shimano Sora D
Shift Levers
Shimano Sora Rapidfire
Cassette
SRAM PG950 11-26
Crank
FSA Omega 48-34 Mega
Bottom Bracket
Shimano Cartridge
Chain
KMC X9 9s
Wheels
Front Hub
Shimano Tiagra
Rear Hub
Shimano Tiagra
Rims
MERIDA Comp V-Pair
Spokes
black stainless-P
Tires
Continental Sport Contact 32
Brakes
Brakes
Avid Single Digit 3
Brake Levers
Avid FR5
Cockpit
Handlebar
MERIDA Pro OS 600 Flat
Headset
EGG Steel Neck
Seat
Saddle
MERIDA Pro SI
Seatpost
Merida Pro H SB15 31.6 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 50cm | 52cm | 54cm | 56cm | 59cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.54 mm | 1.56 mm | 1.58 mm | 1.65 mm | 1.71 mm | 1.73 mm |
| Stack | 568 mm | 581 mm | 591 mm | 611 mm | 637 mm | 661 mm |
| Reach | 370 mm | 372 mm | 373 mm | 371 mm | 373 mm | 381 mm |
| Top Tube Length | 527 mm | 532 mm | 542 mm | 552 mm | 567 mm | 582 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 470 mm | 500 mm | 520 mm | 540 mm | 560 mm | 590 mm |
| Head Tube Angle | 71 ° | 72 ° | 72 ° | 72.5 ° | 73 ° | 73 ° |
| Head Tube Length | 150 mm | 160 mm | 170 mm | 190 mm | 215 mm | 240 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Speeder T3 completes the Merida Speeder model. 90 bikes variations carry this model name so far. Take a sneak peek at all Merida Speeder bikes models from 2014, by clicking here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Fitness bikes
According to our math, the average price for a trustworthy Fitness bike is 656$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Fitness bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Fitness bikes average weight
Fitness bikes have an average weight of 11.24 kg (24.78 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Merida Speeder T3 it’s weighing 10.2 kg (22.49 lbs). At this weight, is considerably lighter than average. In short, the average Fitness bike weight is 10.2% higher than this one.
Overview of components
Wheels size
When it comes to wheels, the Speeder T3 bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Merida Speeder T3 is equipped with Rim brakes. Rim brakes deliver an average performance overall. However, you could spend a little extra and get a bike that has hydraulic brakes.
