Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Dura-Ace Di2 -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
TIME-WARP TRI CF5 IV, material: carbon, 700x30C max. wheelsize, 100x12/ 142x12mm axle standard, Pressfit 86,5
Suspension Fork
TIME-WARP TRI CF5 IV disc, material: carbon, 700x30C max. wheelsize
Drivetrain
Rear Derailleur
Shimano Dura Ace Di2
Front Derailleur
Shimano Dura Ace Di2
Shift Levers
Shimano ST-R9180
Cassette
Shimano CS-R9200, 11-30 teeth, 12 speed
Crank
Shimano Dura Ace, 52-36 teeth, Power Meter, 165 mm-XS, 170 mm-S, 172.5 mm-M, 175 mm-L
Bottom Bracket
Shimano SM-BB92-41B, Pressfit 86.5 mm
Chain
Shimano CN-M9100-12
Wheels
Rims
Vision Metron 81 SL Clincher TL Disc, 100x12mm width front hub, 142x12mm width rear hub, 21mm inner width, 81mm height, Centerlock, material: carbon, Tubeless ready (tubeless tape and valves not included)
Tires
Continental Grand Prix 5000S TR, 700x28C, fold, tubeless ready
Brakes
Brakes
Shimano Dura Ace, Hydraulic disc
Brake Levers
Shimano Dura Ace
Cockpit
Handlebar
MERIDA Metron TT, material: carbon
Headset
MERIDA TIME WARP TT
Seat
Saddle
Prologo TGALE TT CPC Nack
Seatpost
MERIDA TEAM TT II, Aero shape, Carbon
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | XXS |
|---|---|---|---|---|
| Stack Reach Ratio | 1.33 mm | 1.37 mm | 1.28 mm | 1.35 mm |
| Bottom Bracket Height | 281 mm | 281 mm | 266 mm | 266 mm |
| Front Center | 575 mm | 579 mm | 617 mm | 640 mm |
| Rake | 42 mm | 43 mm | 43 mm | 43 mm |
| Trail | 71 mm | 64 mm | 64 mm | 64 mm |
| Stack | 488 mm | 510 mm | 525 mm | 566 mm |
| Reach | 368 mm | 373 mm | 409 mm | 419 mm |
| Top Tube Length | 482 mm | 502 mm | 542 mm | 562 mm |
| Seat Tube Angle | 77 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 460 mm | 500 mm | 540 mm | 580 mm |
| Head Tube Angle | 71 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 110 mm | 130 mm | 130 mm | 173 mm |
| Chainstay Length | 407 mm | 407 mm | 407 mm | 407 mm |
| Wheelbase | 976 mm | 980 mm | 1014 mm | 1037 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 70 mm | 70 mm |
| Standover Height | 744 mm | 773 mm | 791 mm | 830 mm |
| Wheels | 700 | 700 | 700 | 700 |
Model Overview
TIME WARP TRI 10K belongs to the Merida Time model. There are 10 bikes that carry this model name. You can get a glimpse at all models from 2024, by clicking on this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Triathlon bikes
According to our calculations, the average cost of a Triathlon bike that is reliable is 4177$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Triathlon bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Overview of components
Fork material
The fork is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
The TIME WARP TRI 10K 2024 bike is equipped with 700c carbon wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Merida TIME WARP TRI 10K is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
