Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 700c -
Groupset Ultegra, 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
WARP TRI CF4
Suspension Fork
Warp Tri-direct-E
Drivetrain
Rear Derailleur
Shimano Ultegra SS
Front Derailleur
Shimano 105 D
Shift Levers
Shimano BS-R1 2 / Shimano BS-R1 11
Cassette
Shimano CS-5800-11 12-25
Crank
FSA Gossamer 50-34 Mega [PF86]
Bottom Bracket
BB86/BB92, press-fit
Chain
KMC X11EL
Wheels
Front Hub
Road Bearing / Road seal Bearing
Rear Hub
Road Bearing / Road seal Bearing
Rims
MERIDA Expert 35 CW pair
Spokes
Double Butted Black stainless
Tires
Continental Grand Sport Race 23 fold
Brakes
Brakes
Shimano 105-direct
Brake Levers
Profile 3oneA
Cockpit
Handlebar
Profile Ozero TT base -T2+ aero clip
Headset
Warp Bearing
Seat
Saddle
MERIDA-2302
Seatpost
Warp Aero carbon
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 51cm | 54cm | 57cm |
|---|---|---|---|
| Stack Reach Ratio | 1.23 mm | 1.3 mm | 1.32 mm |
| Bottom Bracket Height | 281 mm | 266 mm | 266 mm |
| Front Center | 612 mm | 639 mm | 665 mm |
| Rake | 43 mm | 43 mm | 43 mm |
| Trail | 70 mm | 64 mm | 64 mm |
| Stack | 495 mm | 548 mm | 580 mm |
| Reach | 401 mm | 423 mm | 438 mm |
| Top Tube Length | 508 mm | 541 mm | 563 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 510 mm | 540 mm | 570 mm |
| Head Tube Angle | 71 ° | 72 ° | 72 ° |
| Head Tube Length | 120 mm | 155.5 mm | 190 mm |
| Chainstay Length | 399 mm | 399 mm | 399 mm |
| Wheelbase | 1005 mm | 1028 mm | 1054 mm |
| Bottom Bracket Drop | 55 mm | 70 mm | 70 mm |
| Standover Height | 771 mm | 789 mm | 819 mm |
| Wheels | 700 | 700 | 700 |
Model Overview
WARP TRI 3000 is part of the Merida Warp model. 18 bikes variations carry this model name so far. Take a sneak peek at all Merida Warp bikes models from 2017, by clicking here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Triathlon bikes
According to our math, the average price for a trustworthy Triathlon bike is 4177$. However, even though the average price of a Triathlon bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Average weight for Triathlon bikes
The average weight for Triathlon bikes is 8.9 kg (19.62 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Merida WARP TRI 3000 it’s weighing 8.91 kg (19.64 lbs). At this weight, is slightly heavier than average. In short, the average Triathlon bike weight is 0.11% lower than this one.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
As for the wheels, Merida WARP TRI 3000 2017, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Merida WARP TRI 3000 is equipped with Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they are not nearly as effective as hydraulic brakes are.
