Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame aluminium -
Wheels 29" -
Travel Front 100mm -
Fork RockShox 35 Silver
-
Groupset Deore, FSA -
Suspension Hardtail -
Motor Bosch 250W 85Nm mid-drive -
Battery Bosch Power Tube 625 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kore- G2. AC Frame. Aluminium 6061 Hydroformed Double butted. TA 12mm. Internal Cable Routing. Boost. Post Mount. Full Integrated battery. Ebike Optimized. Head Tube Tapered 1.5
Suspension Fork
Rock Shox 35 Silver Air Crown 15 Boost. E-bike. Travel 100mm. Tapered.
Drivetrain
Shift Levers
Shimano Deore M6100 12V
Cassette
Shimano Deore M6100 12V 10-51
Crank
Fsa Forged E-bike 34
Chain
Shimano Deore M6100 12V
Wheels
Rims
XCR Tryp Hybrid DW Alloy 6063 MS TLR
Tires
Hutchinson Griffus TLR Sideskin 29x2.50
Brakes
Brakes
Shimano MT-200 180/160
Cockpit
Stem
Ritchey Trail
Handlebar
Ritchey Comp 2x720mm
Headset
Ritchey Pro Press Fit Tapered 1.5
Seat
Saddle
San Marco GND Dynamic
Seatpost
Ritchey Comp Zero 30.9
Motor & Battery
Motor
Bosch Performance Line CX
Battery
Bosch Power Tube 625
Remote
Bosch Purion
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.58 mm | 1.53 mm | 1.49 mm | 1.46 mm |
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | 314 mm |
| Front Center | 694 mm | 718 mm | 737 mm | 756 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 95 mm | 95 mm | 95 mm | 95 mm |
| Stack | 629 mm | 639 mm | 647 mm | 657 mm |
| Reach | 399 mm | 419 mm | 434 mm | 449 mm |
| Top Tube Length | 581 mm | 604 mm | 621 mm | 639 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 394 mm | 432 mm | 483 mm | 533 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 464 mm | 464 mm | 464 mm | 464 mm |
| Wheelbase | 1152 mm | 1176 mm | 1195 mm | 1214 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
KORE 10 completes the Mmr E Kore model. MMR launched 5 e-bikes of this model so far. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
MMR KORE 10 2022 is the cheapest e-bike model and costs 3715$. MMR KORE 00 2022 is the most expensive one and costs 4352$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Crosscountry e-bikes average price
If you want an acceptable Crosscountry e-bike you should know that the average price is 2453$. However, you could also get a good Crosscountry e-bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
This e-bike was released in 2022 and its price was 3715$. Doing a quick comparison, we notice that KORE 10 price is 51.45% higher than the average cost of a Crosscountry e-bike.
Internal Cable Routing
It’s also important to mention the internal cable routing that this e-bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
KORE 10 components
Fork
The KORE 10 comes factory-installed with the RockShox 35 Silver fork. This has a travel range of 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
The KORE 10 2022 e-bike is equipped with 29″ aluminum wheels when leaving the factory. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
For your safety, it is important to have quality breaks on your bike. MMR KORE 10 has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
