Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork RockShox 35 Silver
-
Groupset SX Eagle, FSA -
Suspension Hardtail -
Motor Bosch 250W 85Nm mid-drive -
Battery Bosch Power Tube 625 -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kore- G2. AC Frame. Aluminum 6061 Hydroformed Double butted. TA 12mm. Internal Cable Routing. Boost. PostMount. Full Integrated battery. Ebike Optimized. Head Tube Tapered 1.5
Suspension Fork
Rock Shox 35 Silver Air Crown 15 Boost. E-bike. Travel 100mm. Tapered
Drivetrain
Rear Derailleur
SRAM SX 12V
Shift Levers
SRAM sx 12v
Cassette
XCR 11-50
Crank
FSA Forged E-bike 34
Chain
YBN 12V
Wheels
Rims
Shimano MT-500 CL HG
Tires
Hutchinson Griffus TLR Sideskin 29x2.50
Brakes
Brakes
Shimano MT-200 180/160
Cockpit
Stem
Ritchey Trail
Handlebar
Ritchey Comp 2x720mm
Headset
Ritchey Pro Press Fit Tapered 1.5
Seat
Saddle
San Marco GND Dynamic
Seatpost
Ritchey Comp Zero 30.9
Motor & Battery
Motor
Bosch Performance Line CX
Battery
Bosch Power Tube 625
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.58 mm | 1.53 mm | 1.49 mm | 1.46 mm |
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | 314 mm |
| Front Center | 694 mm | 718 mm | 737 mm | 756 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 95 mm | 95 mm | 95 mm | 95 mm |
| Stack | 629 mm | 639 mm | 647 mm | 657 mm |
| Reach | 399 mm | 419 mm | 434 mm | 449 mm |
| Top Tube Length | 581 mm | 604 mm | 621 mm | 639 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 394 mm | 432 mm | 483 mm | 533 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 464 mm | 464 mm | 464 mm | 464 mm |
| Wheelbase | 1152 mm | 1176 mm | 1195 mm | 1214 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Kore 10 belongs to the Mmr E Kore model. 5 e-bikes variations carry this model name so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
The most economical model, the MMR Kore 10 2023 has a starting price of 3928$. MMR Kore 2023 on the other hand is the most expensive at 4565$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Crosscountry e-bikes
According to our math, the average price for a trustworthy Crosscountry e-bike is 2453$. However, you could also get a good Crosscountry e-bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, MMR Kore 10 price was 3928$. If we compare this with the average Crosscountry e-bike cost we notice that the price is 60.13% higher.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Overview of components
Fork
The Kore 10 comes factory-installed with the RockShox 35 Silver fork. This has a travel range of 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
The Kore 10 2023 e-bike is equipped with 29″ aluminum wheels when leaving the factory. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
When you want to stop the bike in time, the brakes are vital. The Kore 10 has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
MMR Kore 10 e-bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
