Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork XCR
-
Groupset Tourney, Altus -
Suspension Hardtail -
Drivetrain 2 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum 6061-T6 double hydroformed crowned, AC Frame, Control & Comfort design, Optimized Cable Routing, Post Mount.
Suspension Fork
XCR 330 Lockout. Black Stanchions. Travel 100mm
Drivetrain
Rear Derailleur
Shimano TX-800 8V
Shift Levers
Shimano Altus M315 8V
Cassette
Shimano HG-31 8V 11-34
Crank
Shimano M-315 22-36
Chain
KMC Z8
Wheels
Rims
XCR DW Alloy 6061 HG
Tires
29 x 2.10
Brakes
Brakes
Zoom HB-875 1607160
Cockpit
Stem
XCR Alloy 4 Bolts
Handlebar
XCR Rizer
Grips
XCR Double Density
Headset
Neco Press Fit 1-1/8
Seat
Saddle
Cionlli Comfort
Seatpost
XCR Alloy 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.72 mm | 1.7 mm | 1.68 mm | 1.65 mm |
| Bottom Bracket Height | 319 mm | 314 mm | 314 mm | 314 mm |
| Front Center | 621 mm | 634 mm | 647 mm | 662 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 84 mm | 84 mm | 84 mm | 84 mm |
| Stack | 611 mm | 625 mm | 635 mm | 644 mm |
| Reach | 356 mm | 367 mm | 379 mm | 390 mm |
| Top Tube Length | 547 mm | 562 mm | 580 mm | 595 mm |
| Seat Tube Angle | 73.5 ° | 73 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 395 mm | 432 mm | 483 mm | 533 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 105 mm | 115 mm | 125 mm | 135 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1055 mm | 1067 mm | 1080 mm | 1095 mm |
| Bottom Bracket Drop | 55 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Kuma 10 is part of the Mmr Kuma model. MMR launched 5 bikes of this model so far. You can easily view all of the Mmr Kuma bikes models from 2023, here.
Model range prices
MMR Kuma 10 2023 is the most affordable bike of this model and has a price of 742$. On the other hand, MMR KUMA 00 2023, is the most expensive and costs 848$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Crosscountry bikes average price
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2023 and its price was 742$. In conclusion, this bike price is 156.74% smaller than the price of the average Crosscountry bike.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork
This bike has the XCR fork installed. The fork’s travel is 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
When it comes to wheels, the Kuma 10 bike is equipped with the 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
