Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame aluminium -
Wheels 29" -
Travel Front 100mm -
Fork RockShox Judy
-
Groupset SX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Woki - G1 Alloy Concept Frame. Aluminiun 6061. Hydroformed Doble Butter. QR. Optimized Cable Routing. Post Mount.
Suspension Fork
RockShox Judy Coil. Travel 100mm. Pop Lock Remote.
Drivetrain
Shift Levers
SRAM SX Eagle 12V
Cassette
SRAM SX Eagle 12V XG-1210 11-50
Crank
SRAM SX Eagle Power Spline 32
Chain
SRAM Eagle 1210 12V
Wheels
Rims
Mavic Crossride FTS-X 29
Tires
Hutchinson Python-2 29x2.10
Brakes
Brakes
Shimano MT-200 160/160
Cockpit
Stem
Ritchey Logic 4 Axis
Handlebar
Ritchey Logic Recto 740 mm
Grips
MMR Double Density Ultragrip
Headset
Ritchey Logic Press Fit 1-1/8
Seat
Saddle
Selle Italia Model X
Seatpost
Ritchey Logic Double Fix 31.6
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.61 mm | 1.61 mm | 1.61 mm | 1.59 mm |
| Bottom Bracket Height | 319 mm | 314 mm | 314 mm | 314 mm |
| Front Center | 638 mm | 652 mm | 662 mm | 677 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 75.5 mm | 75.5 mm | 75.5 mm | 75.5 mm |
| Stack | 605 mm | 619 mm | 628 mm | 638 mm |
| Reach | 376 mm | 385 mm | 391 mm | 402 mm |
| Top Tube Length | 555 mm | 570 mm | 585 mm | 600 mm |
| Seat Tube Angle | 73.5 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 395 mm | 432 mm | 483 mm | 533 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1072 mm | 1085 mm | 1095 mm | 1110 mm |
| Bottom Bracket Drop | 55 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
WOKI 50 is part of the Mmr Woki model. 13 bikes variations carry this model name so far. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
MMR WOKI 30 2022 is the most economical model, with a starting price of 1009$. MMR WOKI 10 2022 on the other hand costs 1115$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Crosscountry bikes
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When MMR released this model in 2022, its price was 1115$. In conclusion, this bike price is 70.85% smaller than the price of the average Crosscountry bike.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
WOKI 50 components
Fork
This bike has the RockShox Judy fork installed. The fork’s travel is 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
When leaving the production line, the WOKI 50 model has 29″ aluminum wheels. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
When you want to stop the bike in time, the brakes are vital. The WOKI 50 has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
