Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork RockShox Judy Silver TK
-
Groupset GX Eagle, Shimano -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Zen - G2 Alloy Concept Lite Frame. Aluminum 6061 Hydroformed double butted. TA 12mm. Optimized, Cable Routing. Boost. PostMount. PressFit. Head tube Tapered 1.5
Suspension Fork
RockShox Judy Silver Air 15 Boost. Fast black. Travel 100mm. One Lock Remote. Tapered
Drivetrain
Rear Derailleur
SRAM GX Eagle 12V
Shift Levers
SRAM GX Eagle 12V
Cassette
SRAM GX Eagle XG-1275 12V 10-52
Crank
Shimano MT-5101 32T
Chain
SRAM Eagle 1210 12V
Wheels
Rims
XCR 9800
Tires
Hutchinson Cobra 29x2.10
Brakes
Brakes
SRAM LEVEL 160/160
Cockpit
Stem
Ritchey Comp 4 Axis
Handlebar
Ritchey Comp 2X Dual Position 9º Sweep 720 mm
Grips
MMR Double Density Ultragrip
Headset
Ritchey Logic Press Fit Tapered
Seat
Saddle
Selle Italia Model
Seatpost
Ritchey Comp Zero Double Fix 31.6
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.51 mm | 1.47 mm | 1.44 mm | 1.4 mm |
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | 314 mm |
| Front Center | 663 mm | 685 mm | 707 mm | 728 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 85 mm | 85 mm | 85 mm | 85 mm |
| Stack | 599 mm | 608 mm | 621 mm | 629 mm |
| Reach | 396 mm | 415 mm | 432 mm | 450 mm |
| Top Tube Length | 567 mm | 589 mm | 609 mm | 630 mm |
| Seat Tube Angle | 74.2 ° | 74.2 ° | 74.2 ° | 74.2 ° |
| Seat Tube Length | 394 mm | 432 mm | 483 mm | 533 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 95 mm | 105 mm | 118 mm | 127 mm |
| Chainstay Length | 439 mm | 439 mm | 439 mm | 439 mm |
| Wheelbase | 1095 mm | 1117 mm | 1139 mm | 1160 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Zen 10 is part of the Mmr Zen model. 9 bikes variations carry this model name so far. Take a sneak peek at all Mmr Zen bikes models from 2023, by clicking here.
Model range prices
MMR Zen 30 2023 is the most economical model, with a starting price of 1672$. MMR ZEN 00 2023 on the other hand costs 1964$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Crosscountry bikes average price
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 1910$. Doing a quick comparison, we notice that Zen 10 price is 0.26% more expensive than the average cost of a Crosscountry bike.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Zen 10 components
Fork
The Zen 10 comes factory-installed with the RockShox Judy Silver TK fork. This has a travel range of 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
The Zen 10 2023 bike is equipped with 29″ aluminum wheels when leaving the factory. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
Zen 10 comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
