Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Fork RockShox Judy
-
Groupset SX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
RockShox Judy Gold, Solo Air, 30mm steel stanchions, 51mm offset
Rear Shock
None
Drivetrain
Rear Derailleur
SRAM SX Eagle 12-speed
Front Derailleur
None
Shift Levers
SRAM SX Eagle 12-speed
Cassette
SRAM PG-1210 Eagle 11-50 tooth 12-speed
Crank
SRAM SX Eagle DUB, 170mm on S and 175mm on M/L/XL
Bottom Bracket
SRAM DUB BSA
Chain
SRAM SX Eagle 12-speed
Chain Guide
None
Pedals
N/A
Wheels
Front Hub
MDK DC711 15x110mm unsealed front and DHT 12x148mm sealed bearing rear
Rear Hub
MDK DC711 15x110mm unsealed front and DHT 12x148mm sealed bearing rear
Rims
MDK-XP1 29 TLR, 23mm internal width, tubeless ready, 32 hole
Spokes
CN round stainless steel
Tires
Maxxis Ikon 29x2.2", 3C MaxxSpeed compound, tubeless ready, 120TPI, folding bead, front and rear
Brakes
Brakes
Shimano MT201, with 160mm RT56 IS 6-bolt rotors, resin pads
Brake Levers
Shimano MT201
Cockpit
Stem
Mondraker Chrono Carbon, 6061 T6 Alloy, +/-5° rise, 31.8mm clamp, 60mm (S/M), 80mm (L), or 90mm (XL) reach
Handlebar
Onoff Sulfur 0.2, rise: 4.8mm, width: 760mm, 9° backsweep, 0° upsweep, 31.8mm clamp
Grips
Onoff Twin, 1lock-on, 135mm
Headset
Onoff Titan, ACB sealed bearings, top 41.8x30.5x8x45°x45°, bottom 51.9x40x8x45°x45°
Seat
Saddle
Mondraker XC Series Chrono Carbon design
Seatpost
OnOff Sulfur 0-R, 6061 T6 Alloy, 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.42 mm | 1.39 mm | 1.37 mm |
| Bottom Bracket Height | 305 mm | 305 mm | 305 mm | 305 mm |
| Stack | 600 mm | 605 mm | 614 mm | 627 mm |
| Reach | 406 mm | 425 mm | 442 mm | 458 mm |
| Top Tube Length | 585 mm | 605 mm | 625 mm | 645 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 395 mm | 430 mm | 470 mm | 520 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 85 mm | 90 mm | 100 mm | 115 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 1081 mm | 1101 mm | 1122 mm | 1143 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 69 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Chrono Carbon is a Mondraker Chrono model. There are 24 bikes that carry this model name. Take a sneak peek at all Mondraker Chrono bikes models from 2020, by clicking here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Crosscountry bikes
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Average weight for Crosscountry bikes
Crosscountry bikes have an average weight of 12.4 kg (27.34 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
With a weight of 11 kg (24.25 lbs), Mondraker bike is considerably lighter than average. In conclusion, the average Crosscountry bike weighs 12.73% more than Chrono Carbon.
Overview of components
Fork
The fork installed on this bike is the RockShox Judy model. The travel on this model is 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Fork material
The fork is made out of steel, so, it can add some extra weight to your bike. However, steel is a pretty tough and durable material.
Wheels
The wheels on Chrono Carbon are the 29″ aluminum type. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
When you want to stop the bike in time, the brakes are vital. The Chrono Carbon has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
