Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Fork RockShox Judy Gold RL
-
Groupset NX Eagle, SX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
RockShox Judy Gold RL, Motion Control damper, Solo Air spring, OneLock 2-position remote compression lockout, rebound adjust, 51mm offset
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM NX Eagle, 12-speed, Type 3 roller bearing clutch, cage lock, X-ACTUATION
Front Derailleur
None
Shift Levers
SRAM SX Eagle, 12-speed, Trigger, X-ACTUATION
Cassette
SRAM NX Eagle PG-1230, 12-speed, 11-50 tooth
Crank
SRAM SX Eagle DUB, 170mm length (SM), 175mm length (MD/LG/XL)
Bottom Bracket
SRAM DUB, sealed bearings, 73mm BSA threaded
Chain
SRAM SX Eagle, 12-speed, PowerLock
Chain Guide
None
Pedals
None
Wheels
Front Hub
Formula, 32 hole, 6-bolt rotor mounts, DC711 110x15mm Boost front, MST148S-4SB 148x12mm Boost rear with HG driver
Rear Hub
Formula, 32 hole, 6-bolt rotor mounts, DC711 110x15mm Boost front, MST148S-4SB 148x12mm Boost rear with HG driver
Rims
MDK-XP1 TLR, 25mm internal width, tubeless ready, 32 hole
Spokes
CN round stainless steel
Tires
Maxxis Ikon, 3C MaxxSpeed, TR, 120 TPI, folding bead, 29" x 2.2"
Brakes
Brakes
SRAM Level, 2-piston, SRAM CenterLine 6-bolt 160mm rotors, steel-backed organic pads
Brake Levers
SRAM Level, lever pivot bushings, tooled reach adjust
Cockpit
Stem
MDK, 6061-T6 alloy, +/-5° rise, 31.8mm bar clamp, Length: 60mm (SM), 70mm (MD), 80mm (LG), 90mm (XL)
Handlebar
ONOFF Sulfur 0.2, double-butted 6061 alloy, 4.8mm rise, 740mm width, 9° backsweep, 0° upsweep, 31.8mm clamp diameter
Grips
ONOFF Twin, 135mm length, single lock-on
Headset
ONOFF Titan, ACB sealed bearings
Seat
Saddle
Mondraker XC Series, steel rails
Seatpost
ONOFF Sulfur 0-R, 3D-forged 6061-T6 alloy, 400mm length
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.42 mm | 1.39 mm | 1.37 mm |
| Bottom Bracket Height | 305 mm | 305 mm | 305 mm | 305 mm |
| Stack | 600 mm | 605 mm | 614 mm | 627 mm |
| Reach | 406 mm | 425 mm | 442 mm | 458 mm |
| Top Tube Length | 585 mm | 605 mm | 625 mm | 645 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 395 mm | 430 mm | 470 mm | 520 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 85 mm | 90 mm | 100 mm | 115 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 1081 mm | 1101 mm | 1122 mm | 1143 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 69 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Chrono Carbon belongs to the Mondraker Chrono model. 24 bikes variations carry this model name so far. Take a sneak peek at all Mondraker Chrono bikes models from 2021, by clicking here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Crosscountry bikes
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Average weight for Crosscountry bikes
On a deeper look, we notice that the average weight of a Crosscountry bike is 12.4 kg (27.34 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Mondraker Chrono Carbon it’s weighing 11.3 kg (24.91 lbs). At this weight, is a bit lighter than average. In short, the average Crosscountry bike weight is 9.73% higher than this one.
Overview of components
Fork
The fork installed on this bike is the RockShox Judy Gold RL model. The travel on this model is 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
When it comes to wheels, the Chrono Carbon bike is equipped with the 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
