Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork RockShox Recon Gold RL
-
Groupset GX Eagle, SX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
RockShox Recon Gold RL, Motion Control damper, DebonAir spring, OneLock 2-position remote compression lockout, rebound adjust, 44mm offset
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM GX Eagle, 12-speed, Type 3 roller bearing clutch, cage lock, X-ACTUATION
Front Derailleur
None
Shift Levers
SRAM SX Eagle, 12-speed, Trigger, X-ACTUATION
Cassette
SRAM SX Eagle PG-1210, 12-speed, 11-50 tooth
Crank
Truvativ Stylo 6K Eagle DUB, 170mm length (SM), 175mm length (MD/LG/XL)
Bottom Bracket
SRAM DUB, sealed bearings, 73mm BSA threaded
Chain
SRAM SX Eagle, 12-speed, PowerLock
Chain Guide
None
Pedals
None
Wheels
Front Hub
Formula, 32 hole, 6-bolt rotor mounts, DC711 110x15mm Boost front, MST148S-4SB 148x12mm Boost rear with HG driver
Rear Hub
Formula, 32 hole, 6-bolt rotor mounts, DC711 110x15mm Boost front, MST148S-4SB 148x12mm Boost rear with HG driver
Rims
MDK-XP1 TLR, 25mm internal width, tubeless ready, 32 hole
Spokes
CN round stainless steel
Tires
Maxxis Ikon, 60 TPI, wire bead, 29" x 2.2"
Brakes
Brakes
SRAM Level, 2-piston, SRAM CenterLine 6-bolt 160mm rotors, steel-backed organic pads
Brake Levers
SRAM Level, lever pivot bushings, tooled reach adjust
Cockpit
Stem
ONOFF Sulfur, 6061-T6 alloy, +/-7° rise, 31.8mm bar clamp, Length: 60mm (SM/MD), 80mm (LG), 90mm (XL)
Handlebar
ONOFF Sulfur 0.2, double-butted 6061 alloy, 4.8mm rise, 740mm width, 9° backsweep, 0° upsweep, 31.8mm clamp diameter
Grips
ONOFF Twin, 135mm length, single lock-on
Headset
ONOFF Saturn, ACB sealed bearings
Seat
Saddle
Mondraker XC Series, steel rails
Seatpost
ONOFF Sulfur 0-R, 3D-forged 6061-T6 alloy, 400mm length
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.53 mm | 1.46 mm | 1.42 mm | 1.4 mm |
| Bottom Bracket Height | 305 mm | 305 mm | 305 mm | 305 mm |
| Stack | 613 mm | 613 mm | 623 mm | 637 mm |
| Reach | 401 mm | 421 mm | 439 mm | 455 mm |
| Top Tube Length | 585 mm | 605 mm | 625 mm | 645 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 395 mm | 430 mm | 470 mm | 520 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 100 mm | 100 mm | 110 mm | 125 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1082 mm | 1102 mm | 1122 mm | 1143 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 69 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Chrono R completes the Mondraker Chrono model. Mondraker released 24 bikes variations of this model so far. Take a sneak peek at all Mondraker Chrono bikes models from 2021, by clicking here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Crosscountry bikes average price
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Crosscountry bikes average weight
Crosscountry bikes have an average weight of 12.4 kg (27.34 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
Weighing 11.8 kg (26.01 lbs), the Chrono R model is a bit lighter than average. In conclusion, the average Crosscountry bike weighs 5.08% more than Chrono R.
Overview of components
Fork
The fork installed on this bike is the RockShox Recon Gold RL model. The travel on this model is 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
The Chrono R 2021 bike is equipped with 29″ aluminum wheels when leaving the factory. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Nothing is more important on a bike than its ability to brake properly. Mondraker Chrono R is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
Chrono R comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
