Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 150mm -
Travel Rear 150mm -
Fork RockShox Recon Silver RL
-
Groupset SX Eagle, Shimano -
Suspension Full -
Motor Shimano 250W 70Nm mid-drive -
Battery Simplo internal integrated 630Wh and Simplo external 360Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
RockShox Recon RL Motion Control, DebonAir, 44mm offset.
Rear Shock
RockShox Deluxe Select R Debonair, 205x65mm Trunnion mount
Drivetrain
Rear Derailleur
SRAM SX Eagle 12-speed
Front Derailleur
None
Shift Levers
SRAM SX Eagle 12-speed
Cassette
SRAM PG-1210 Eagle 11-50 tooth 12-speed
Crank
Shimano E8000, 165mm
Chain
SRAM SX Eagle 12-speed
Chain Guide
None
Pedals
N/A
Wheels
Front Hub
MDK DC711 looseball Boost front and EHL148 sealed bearing rear
Rear Hub
MDK DC711 looseball Boost front and EHL148 sealed bearing rear
Rims
MDK-HP1 29, 30mm internal width, tubeless ready, 32 hole
Spokes
CN stainless steel
Tires
Maxxis Rekon 29x2.6 tubeless ready, Dual compound, EXO, 60TPI, folding bead front and rear
Brakes
Brakes
Shimano MT501 with 203mm RT66 six-bolt rotors, resin pads
Brake Levers
Shimano MT501
Cockpit
Stem
Onoff Krypton FG 30mm reach, 6061 forged alloy, 35mm clamp
Handlebar
OnOff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 780mm, 9° backsweep, 5° upsweep, 31.8mm clamp
Grips
Onoff Desert, 1lock-on, 135mm
Headset
Onoff Saturn, ACB sealed bearings, top 41x30.2x7x45°x45°, bottom 51.9x40x8x45°x45°
Seat
Saddle
Mondraker e-MTB
Seatpost
Onoff Pija, 337x100mm on S, 387x125mm on M, 425x150mm on L/XL
Motor & Battery
Motor
Shimano E8000
Battery
Simplo internal integrated 630Wh and Simplo external 360Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.37 mm | 1.3 mm | 1.25 mm |
| Bottom Bracket Height | 353 mm | 353 mm | 353 mm | 353 mm |
| Stack | 617 mm | 617 mm | 635 mm | 635 mm |
| Reach | 450 mm | 450 mm | 490 mm | 510 mm |
| Top Tube Length | 599 mm | 619 mm | 644 mm | 664 mm |
| Seat Tube Angle | 76.3 ° | 76.3 ° | 76.3 ° | 76.3 ° |
| Seat Tube Length | 380 mm | 420 mm | 450 mm | 490 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 110 mm | 110 mm | 130 mm | 130 mm |
| Chainstay Length | 452 mm | 452 mm | 452 mm | 452 mm |
| Wheelbase | 1222 mm | 1242 mm | 1262 mm | 1282 mm |
| Bottom Bracket Drop | 21 mm | 21 mm | 21 mm | 21 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Dusk R completes the Mondraker E Dusk model. 9 e-bikes variations carry this model name so far. Check out the entire range from 2020 of this model, by clicking this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Enduro e-bikes average price
According to our math, the average price for a trustworthy Enduro e-bike is 4785$. However, even if your budget is less than the average, you might still be able to get a top-quality Enduro e-bike. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
Enduro e-bikes average weight
The average weight for Enduro e-bikes is 23.42 kg (51.63 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Mondraker Dusk R it’s weighing 22.8 kg (50.27 lbs). At this weight, is slightly lighter than average. In short, the average Enduro e-bike weight is 2.72% higher than this one.
Overview of components
Fork
The Dusk R comes factory-installed with the RockShox Recon Silver RL fork. This has a travel range of 150mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
The shock that’s installed on this e-bike is RockShox Deluxe Select R Debonair, with a travel distance of 150mm. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
When leaving the production line, the Dusk R model has 29″ aluminum wheels. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, the 29″ wheels will add a little more weight to the e-bike itself.
Brakes
When you want to stop the bike in time, the brakes are vital. The Dusk R has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
