Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 160mm -
Travel Rear 140mm -
Fork Fox Performance Float 36
-
Groupset NX, Race Face -
Suspension Full -
Motor Bosch 250W 75Nm mid-drive -
Battery Bosch PowerTube -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
FOX 36 Float Grip EVOL Performance, Boost
Rear Shock
FOX Float DPX2 LV EVOL Performance, Trunnion top mount, 205mm x 62.5mm
Drivetrain
Rear Derailleur
SRAM NX, Type 3 with roller bearing clutch and cage lock, X-Horizon system
Front Derailleur
N/A
Shift Levers
SRAM NX, 11-speed, trigger
Cassette
SRAM PG-1130, 11-42 tooth, 11-speed
Crank
Race Face Aeffect
Chain
SRAM PC-1110, 11-speed
Chain Guide
N/A
Pedals
None included
Wheels
Front Hub
Front: DT Swiss 370, Boost 15mm x 110mm, 6 bolt, Rear: DT Swiss 370, Boost 12mm x 148mm, 6 bolt
Rear Hub
Front: DT Swiss 370, Boost 15mm x 110mm, 6 bolt, Rear: DT Swiss 370, Boost 12mm x 148mm, 6 bolt
Rims
DT Swiss H1900 Spline, 35mm internal width, e-bike specific, tubeless ready, 28 hole
Spokes
Hybrid system, stainless steel
Tires
Front: Maxxis Minion DHF 2.8", tubeless ready, Dual compound, EXO Protection, 60TPI, folding, Rear: High Roller 27 II 2.8", tubeless ready, Dual compound, EXO Protection, 60TPI, folding
Brakes
Brakes
SRAM Guide RE with 200mm Centerline rotors
Brake Levers
SRAM Guide RE
Cockpit
Stem
Onoff Stoic FG, forged 6061 alloy, 30mm length, 31.8mm clamp
Handlebar
Mondraker Custom Design 1.0, 780mm width
Grips
Onoff Diamond Lock-on, 130mm
Headset
Onoff Saturn
Seat
Saddle
Mondraker E-mtb
Seatpost
Onoff Pija, 100mm drop (S), 125mm drop (M-XL)
Motor & Battery
Motor
Bosch Performance Line CX
Battery
Bosch PowerTube
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.34 mm | 1.3 mm | 1.29 mm | 1.25 mm |
| Bottom Bracket Height | 340 mm | 340 mm | 340 mm | 340 mm |
| Stack | 597 mm | 615 mm | 633 mm | 642 mm |
| Reach | 447 mm | 472 mm | 492 mm | 512 mm |
| Top Tube Length | 607 mm | 637 mm | 662 mm | 685 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 380 mm | 420 mm | 470 mm | 500 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 100 mm | 120 mm | 140 mm | 150 mm |
| Chainstay Length | 472 mm | 472 mm | 472 mm | 472 mm |
| Wheelbase | 1232 mm | 1265 mm | 1293 mm | 1317 mm |
| Bottom Bracket Drop | 15 mm | 15 mm | 15 mm | 15 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
e-Crafty XR+ is part of the Mondraker E E Crafty model. 2 e-bikes variations carry this model name so far. Check out the entire range from 2018 of this model, by clicking this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Trail e-bikes average price
According to our math, the average price for a trustworthy Trail e-bike is 3365$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail e-bike. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
Trail e-bikes average weight
On a deeper look, we notice that the average weight of a Trail e-bike is 23.7 kg (52.25 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
e-Crafty XR+ weighs 24.1 kg (53.13 lbs) and is slightly heavier than the average. In other words, this model is 1.69% heavier than the average Trail e-bike.
e-Crafty XR+ components
Fork
The e-Crafty XR+ comes factory-installed with the Fox Performance Float 36 fork. This has a travel range of 160mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
The shock that’s installed on this e-bike is FOX Float DPX2 LV EVOL Performance, with a travel distance of 140mm. Rear shocks improve riding comfort and give you greater control over all terrains. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
The wheels on e-Crafty XR+ are the 27.5″ aluminum type. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Mondraker e-Crafty XR+ has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
This e-bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
Dropper post
A dropper post is included with the e-Crafty XR+. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
