Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 140mm -
Travel Rear 120mm -
Fork RockShox Revelation RC
-
Groupset NX -
Suspension Full -
Motor Bosch 250W 75Nm mid-drive -
Battery Bosch PowerTube -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
Rockshox Revelation RC Solo Air, Boost
Rear Shock
RockShox Monarch RT Solo Air, 200mm x 57mm
Drivetrain
Rear Derailleur
SRAM NX,Type 3 with roller bearing clutch and cage lock, long cage, X-Horizon system
Front Derailleur
N/A
Shift Levers
SRAM NX1, 11-speed, trigger, Zero Loss technology, Exact actuation
Cassette
SRAM PG-1130, 11-42 tooth, 11-speed
Crank
Miranda Delta
Chain
SRAM PC-1110
Chain Guide
N/A
Pedals
None included
Wheels
Front Hub
MDK Pro II, Boost front and rear
Rear Hub
MDK Pro II, Boost front and rear
Rims
NEW MDK-EP1 Asy 35 TLR
Spokes
CN stainless
Tires
Maxxis Rekon 2.8", tubeless ready, Dual compound, Exo-protection, 60TPI, folding
Brakes
Brakes
SRAM Level T with 200mm front/180mm rear Centerline rotors, organic pads
Brake Levers
SRAM Level T
Cockpit
Stem
Onoff Stoic FG, forged 6061 alloy, 30mm length, 31.8mm clamp
Handlebar
Mondraker Custom Design 0.5, 760mm width
Grips
Onoff Diamond Lock-on, 130mm
Headset
Onoff Saturn
Seat
Saddle
Mondraker factor XR+
Seatpost
Onoff Pija, 100mm drop (S), 125mm drop (M-XL)
Motor & Battery
Motor
Bosch Performance Line CX
Battery
Bosch PowerTube
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.3 mm | 1.24 mm | 1.21 mm | 1.19 mm |
| Bottom Bracket Height | 330 mm | 330 mm | 330 mm | 330 mm |
| Stack | 583 mm | 583 mm | 597 mm | 611 mm |
| Reach | 447 mm | 472 mm | 492 mm | 512 mm |
| Top Tube Length | 604 mm | 629 mm | 652 mm | 676 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 380 mm | 420 mm | 470 mm | 510 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 100 mm | 100 mm | 115 mm | 130 mm |
| Chainstay Length | 472 mm | 472 mm | 472 mm | 472 mm |
| Wheelbase | 1208 mm | 1234 mm | 1259 mm | 1285 mm |
| Bottom Bracket Drop | 25 mm | 25 mm | 25 mm | 25 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
e-Factor XR+ belongs to the Mondraker E E Factor model. There are 2 e-bikes that carry this model name. You can get a glimpse at all models from 2018, by clicking on this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Trail e-bikes average price
According to our math, the average price for a trustworthy Trail e-bike is 3365$. However, you could also get a good Trail e-bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
Average weight for Trail e-bikes
On a deeper look, we notice that the average weight of a Trail e-bike is 23.7 kg (52.25 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
With a weight of 22.4 kg (49.38 lbs), Mondraker e-bike is a bit lighter than average. In short, the average Trail e-bike weight is 5.8% higher than this one.
Overview of components
Fork
The RockShox Revelation RC is included from the factory. It has a travel distance of 140mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
From the factory, it comes with the RockShox Monarch RT Solo Air rear shock model, which has a travel of 120mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
As for the wheels, Mondraker e-Factor XR+ 2018, has a 27.5″ aluminum model. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The e-Factor XR+ has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
This e-bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
The Mondraker model is also equipped with a dropper post. Therefore, climbing or descending will be a breeze.
