Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 24" -
Travel Front 100mm -
Travel Rear 100mm -
Fork RockShox Judy Silver TK
-
Groupset Deore -
Suspension Full -
Motor MAHLE hub-drive -
Battery Mahle-Ebikemotion Internal 250Wh -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
F-Play 24 6061 Alloy Stealth evo, hydroformed tubing, Zero Suspension System, 100mm travel, one piece bolt-on upper link, integrated internal non-removable battery, Tapered head tube, HHG internal cable routing, BSA bottom bracket, QR 9mm rear axle, 1x drivetrain compatible
Suspension Fork
RockShox Judy Silver TK 26, 100mm, TurnKey, Solo Air, tapered steerer tube, 9x135mm axle, 30mm steel stanchions, 40mm offset. Settings: compression adjustment at low-speed to lock, rebound, air preload
Rear Shock
SR Suntour Raidon R, 210x47.5mm. Settings: low-speed rebound, air preload. 45x8mm top and bottom bushings
Drivetrain
Shift Levers
Shimano Deore M4100R, Rapid Fire Plus, 10s
Crank
Samox, Direct mount chain ring, 155mm
Bottom Bracket
Samox BSA, 73mm
Chain
Shimano HG54, 10s
Wheels
Front Hub
Formula DC20LW, 9x135mm, cup & cone ball bearings, IS 6 bolts
Rear Hub
Mahle-Ebikemotion X-35
Rims
MDK-XP1 24 TLR, 23mm internal width, tubeless ready, 32 spokes
Spokes
CN round stainless steel
Tires
Kenda Booster 24x2.4 single compound 30TPI, wire bead
Brakes
Brakes
Tektro Auriga HDM291 hydraulic, 160mm IS 6 bolts rotor
Brake Levers
Tektro Auriga HDM291 hydraulic
Cockpit
Stem
MDK XC, 6061 forged alloy, 31.8mm barbore, rise: 0º, length: 35mm
Handlebar
MDK XC 1.0, 6061 alloy, rise: 25mm, width: 680mm, 9º backsweep, 5º upsweep, 31.8mm barbore
Grips
Onoff Twin, 1lock-on, 135mm
Headset
Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º
Seat
Saddle
SDG Fly JR
Seatpost
MDK XC 0-R, 6061 T6 Alloy, diameter 31.6mm, length 300mm
Motor & Battery
Motor
Mahle-Ebikemotion X-35
Battery
Mahle-Ebikemotion Internal 250Wh
Remote
Mahle-Ebikemotion
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | Frame size | 24" |
|---|---|---|
| Wheels | 24" | 24" |
About this model
F-PLAY 24 belongs to the Mondraker E F Play model. Mondraker launched 6 e-bikes of this model so far. Take a sneak peek at all Mondraker E F Play e-bikes models from 2022, by clicking here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Youth e-bikes
According to our math, the average price for a trustworthy Youth e-bike is 1895$. However, you could also get a good Youth e-bike even if you pay a lower amount than the average price. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
Youth e-bikes average weight
On a deeper look, we notice that the average weight of a Youth e-bike is 17.49 kg (38.56 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
With a weight of 16.4 kg (36.16 lbs), Mondraker e-bike is a bit lighter than average. To sum up, it’s 6.65% lighter than the average weight of Youth e-bikes.
Internal Cable Routing
It’s also important to mention the internal cable routing that this e-bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork
The F-PLAY 24 comes factory-installed with the RockShox Judy Silver TK fork. This has a travel range of 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Fork material
When it comes to the fork, this e-bike has a steel one, so, it can add some extra weight to your bike. However, steel is a pretty tough and durable material.
Rear Shock
From the factory, it comes with the SR Suntour Raidon R rear shock model, which has a travel of 100mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
The wheels on F-PLAY 24 are the 24″ aluminum type. The 24″ wheels are a good fit for folding bikes, BMX, or children bikes. In conclusion, they are great for flat ground or very easy trails.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The F-PLAY 24 comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
