Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 120mm -
Travel Rear 100mm -
Fork Fox Performance Float 34
-
Groupset GX Eagle, NX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
FOX 34 Float GRIP EVOL Step-Cast Performance, remote lockout, 44mm offset
Rear Shock
FOX Float DPS SV EVOL Performance Elite, 185x47.5mm Trunnion mount
Drivetrain
Rear Derailleur
SRAM GX Eagle 12-speed
Front Derailleur
None (1x only)
Shift Levers
SRAM NX Eagle 12-speed
Cassette
SRAM XG-1275 Eagle 10-50 tooth 12-speed
Crank
Truvativ Stylo 7K Eagle, 170mm on S/M and 175mm on L/XL
Bottom Bracket
SRAM DUB BSA
Chain
SRAM NX Eagle 12-speed
Chain Guide
None
Pedals
N/A
Wheels
Front Hub
Mavic Boost 6-bolt front and rear, ID360 rear
Rear Hub
Mavic Boost 6-bolt front and rear, ID360 rear
Rims
Mavic Crossmax 29, 25mm internal width, asymmetric, tubeless ready, 24 hole
Spokes
Mavic steel
Tires
Maxxis Rekon Race, EXO, tubeless ready, 120TPI, folding bead, 2.35" front and 2.25" rear
Brakes
Brakes
Shimano MT501 with 180mm RT56 IS 6-bolt rotors, resin pads
Brake Levers
Shimano MT501
Cockpit
Stem
Mondraker Chrono Carbon, 6061 T6 Alloy, 31.8mm clamp, rise: +/-5°, 50mm (S/M) or 60mm (L/XL) reach
Handlebar
Onoff Sulfur 0.2, rise: 4.8mm, width: 760mm, 9° backsweep, 0° upsweep, 31.8mm clamp
Grips
Onoff Desert, 1lock-on, 135mm
Headset
Onoff Saturn, ACB sealed bearings, top 41x30.2x7x45°x45°, bottom 51.9x40x8x45°x45°
Seat
Saddle
Fizik Antares R7
Seatpost
Onoff Pija internally routed dropper, 337x100mm on S, 387x125mm on M, 425x150mm on L/XL
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.34 mm | 1.29 mm | 1.25 mm | 1.23 mm |
| Bottom Bracket Height | 337 mm | 337 mm | 337 mm | 337 mm |
| Stack | 584 mm | 589 mm | 598 mm | 612 mm |
| Reach | 437 mm | 457 mm | 477 mm | 497 mm |
| Top Tube Length | 590 mm | 610 mm | 636 mm | 661 mm |
| Seat Tube Angle | 75.1 ° | 75.1 ° | 75.1 ° | 75.1 ° |
| Seat Tube Length | 390 mm | 420 mm | 470 mm | 510 mm |
| Head Tube Angle | 66.8 ° | 66.8 ° | 66.8 ° | 66.8 ° |
| Head Tube Length | 85 mm | 90 mm | 100 mm | 115 mm |
| Chainstay Length | 439 mm | 439 mm | 439 mm | 439 mm |
| Wheelbase | 1153 mm | 1174 mm | 1198 mm | 1224 mm |
| Bottom Bracket Drop | 37 mm | 37 mm | 37 mm | 37 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
F-Podium DC R completes the Mondraker F Podium model. There are 23 bikes that carry this model name. Check out the entire range from 2020 of this model, by clicking this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Crosscountry bikes average price
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Crosscountry bikes average weight
Crosscountry bikes have an average weight of 12.4 kg (27.34 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
Weighing 11.9 kg (26.23 lbs), the F-Podium DC R model is slightly lighter than average. In other words, this model is 4.2% lighter than the average Crosscountry bike.
Overview of components
Fork
The Fox Performance Float 34 is included from the factory. It has a travel distance of 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
The shock that’s installed on this bike is FOX Float DPS SV EVOL Performance Elite, with a travel distance of 100mm. Rear shocks improve riding comfort and give you greater control over all terrains. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
When it comes to wheels, the F-Podium DC R bike is equipped with the 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
When you want to stop the bike in time, the brakes are vital. The F-Podium DC R has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
F-Podium DC R comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
The Mondraker model is also equipped with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
