Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 160mm -
Travel Rear 150mm -
Fork Fox Performance Float 36
-
Groupset GX Eagle, Truvativ Descendant -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
FOX 36 Float FIT Grip EVOL Performance, 44mm offset
Rear Shock
FOX Float DPX2 LV EVOL Performance, 205x62.5mm, Trunnion mount
Drivetrain
Rear Derailleur
SRAM GX Eagle 12-speed
Front Derailleur
None (1x only)
Shift Levers
SRAM GX Eagle 12-speed
Cassette
SRAM XG-1275 GX Eagle, 10-50 tooth, 12-speed
Crank
Truvativ Descendant 6K, 170mm on S/M and 175mm on L/XL
Bottom Bracket
SRAM DUB BSA
Chain
SRAM NX Eagle, 12-speed
Chain Guide
None
Pedals
N/A
Wheels
Front Hub
DT Swiss 370 Boost
Rear Hub
DT Swiss 370 Boost
Rims
DT Swiss E1900 Spline 29, 30mm internal width, tubeless ready, 28 hole
Spokes
DT Swiss Champion straight pull
Tires
Maxxis Minion DHR II 2.4WT, Tubeless ready, 3C Maxx Terra, EXO, 60TPI, folding bead front and Maxxis Aggressor 2.3", Tubeless ready, 3C Maxx Terra, EXO, 60TPI, folding bead rear
Brakes
Brakes
SRAM G2 with metal sintered pads, with 200mm CenterLine 6-bolt rotors
Brake Levers
SRAM G2
Cockpit
Stem
Onoff Sulfur FG 30mm reach 0°, 6061 forged alloy, 31.8 mm clamp
Handlebar
OnOff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 780mm, 9° backsweep, 5° upsweep, 31.8mm clamp
Grips
Onoff Desert, 1lock-on, 135mm
Headset
Onoff Titan, ACB sealed bearings, top 41.8x30.5x8x45°x45°, bottom 51.9x40x8x45°x45°
Seat
Saddle
SDG Fly MTN, PU foam, Cr-Mo rails, Cordura sides
Seatpost
Onoff Pija, 337x100mm on S, 387x125mm on M, 425x150mm on L/XL
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.35 mm | 1.3 mm | 1.27 mm | 1.25 mm |
| Bottom Bracket Height | 355 mm | 355 mm | 355 mm | 355 mm |
| Stack | 603 mm | 612 mm | 627 mm | 640 mm |
| Reach | 447 mm | 472 mm | 492 mm | 512 mm |
| Top Tube Length | 603 mm | 626 mm | 651 mm | 675 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 380 mm | 420 mm | 470 mm | 510 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 90 mm | 100 mm | 115 mm | 130 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1190 mm | 1219 mm | 1245 mm | 1271 mm |
| Bottom Bracket Drop | 19 mm | 19 mm | 19 mm | 19 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Foxy R completes the Mondraker Foxy model. There are 33 bikes that carry this model name. You can get a glimpse at all models from 2020, by clicking on this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Enduro bikes average price
According to our calculations, the average cost of an Enduro bike that is reliable is 3599$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Enduro bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Enduro bikes average weight
Enduro bikes have an average weight of 14.27 kg (31.46 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Weighing 14.9 kg (32.85 lbs), the Foxy R model is slightly heavier than average. In conclusion, the average Enduro bike weighs 4.41% less than Foxy R.
Foxy R components
Fork
The fork installed on this bike is the Fox Performance Float 36 model. The travel on this model is 160mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
As for the rear shock, this bike has the FOX Float DPX2 LV EVOL Performance model, with a travel of 150mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
The wheels on Foxy R are the 29″ aluminum type. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
When you want to stop the bike in time, the brakes are vital. The Foxy R has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
Mondraker Foxy R bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
